Name: CNC 6040 4 Axis Mini CNC Router 2.2KW Spindle Motor Engraving Milling Machine
SKU: 211431348019181
Availability: InStock

CNC 6040 4 Axis Mini CNC Router 2.2KW Spindle Motor Engraving Milling Machine

 8,704.13 –  9,849.41

Saudi riyal (ر.س) - SAR

Saudi riyal (ر.س) - SAR
United States dollar ($) - USD
United Arab Emirates dirham (د.إ) - AED

Compare

Product Description

CNC Router Engraver6040 2.2KW USB Milling Machine

Introduction

The CNC router is suitble for Industry, Technology Research, Advertising Design, Arts Creation, Teaching, Student Project and Hobby Purposes.

The cnc router is designedfor large area engraving work such as Industrial or Hobby Prototype Building, Building Model Making, PCB, Advertising Signs, Artwork, Crafts, Aircraft Models, RC Model parts, etc. So, you can do engraving work at office or home.

Shipping by DHL FEDEX UPS with tracking number

Technical Parameters

MODEL	6040Z-S2.2KW
Attribute	LPT 3axis	LPT 4axis	USB 3axis	USB 4axis
Axis	3axis	4axis	3axis	4axis
Interface	LPT port	LPT port	USB port	USB Port
Limit switch	No	No	No	No
Toolauto-checking	No	No	No	No
Spindle Motor:	2.2KW	2.2KW	2.2KW	2.2KW
Type of screw	1605 Ball screw	1605 Ball screw	1605 Ball screw	1605 Ball screw
Weigh	56KG	61KG	57KG	62KG
Machine Dimensions:	860X690X550mm
Rack material:	6061 and 6063 Hard aluminum alloy (The unique and dedicated mold extrusion profiles, Let counterfeiters dwarfs.)
Engraving area:	600X400mm
Z-Axis Stroke:	80mm, Engraving depth depends on the length of the tool edge
Acceptable material thickness:	≤80mm
Rail type:	Chromeplate shaft+Linear Bearings,Surface hardening 61HRC
Spindle motor:	NEW 2.2KW VFD water cooling spindle
Collet type:	ER16,1/8″(3.175mm) Collet
Stepper motor and drive:	two-phase hybrid stepping motor3A/PHASE,150N.cm, 8 segments drive.
Maximum operating speed:	4000mm/min (Engraving speed : 300-3000mm/min)
Repeat positioning Accuracy:	≤0.03mm
Software Compatability:	Mach3/Emc2/Kcam, (Type3,Wentai, ArtCAM,coppercam)
Command code:	G code/.nc/.ncc/.tab/.txt
Rotation Axis (4^th Axis) Description:	Chuck Size: 50mm self-centering chuck Center height: H = 51mm Clamping diameter: 50mm or less Deceleration mode: synchronous wheel / belt Deceleration ratio: 4:1 Stepper motor:NEW 57 type / 3A Stepper Drive: T65-axis drive Positioning accuracy: 0.075 ° Weight: 4kg
