Chinese Top Brand competitive land Motor Grader Tractor
Self-propelled articulated motor grader is suitable for large-scale land leveling in foundation constructions. It can be used for ditching,grading, slope scraping, bulldozing,ripping,virgin land scarifying and snow-removing etc., which is modernized construction equipment of multifunctions and high-efficiency for high-class highway, railway, airport, harbors, dams, industrialground and farmland.
| Technical Parameters | |
| Model | JKG-165 |
| Operating weight | 15000kg |
| Front axle load | 4150kg |
| Rear axle load | 10850kg |
| Max.forward speed | 40.4km/h |
| Max.backward speed | 25.7km/h |
| Speed gear number | F6/R3 |
| Turning radius | 7500mm |
| Hydraulic system pressure | 18Mpa |
| Blade length*height | 3660*610mm |
| Front wheeltrack | 2150mm |
| Rear wheeltrack | 2255mm |
| Wheelbase | 5347mm |
| Engine model | CUMMINS, 6BTA5.9 |
| Engine power | 125kw/170hp |
| Overall dimension | 8305*2695*3420mm |
If this model VTG-165 can not meet your requests, we have other models. When you send an inquiry, I would appreciate it if you tell me which model you are interested in:
| Technical Parameters | |||
| Model | JKG-135 | JKG-180 | JKG-220 |
| Operating weight | 13800kg | 16000kg | 16900kg |
| Front axle load | 4000kg | 5150kg | 5820kg |
| Rear axle load | 9800kg | 10850kg | 11080kg |
| Max.forward speed | 38.3km/h | 36/38.2km/h | 36.8km/h |
| Max.backward speed | 24.4km/h | 25/24.5km/h | 24.8km/h |
| Speed gear number | F6/R3 | F6/R3 | F6/R3 |
| Turning radius | 7500mm | 7800mm | 7800mm |
| Hydraulic system pressure | 18Mpa | 18Mpa | 18Mpa |
| Blade length * height | 3660*610mm | 3965*610mm | 3965*610mm |
| Front wheeltrack | 2150mm | 2150mm | 2150mm |
| Rear wheeltrack | 2165mm | 2255mm | 2225mm |
| Wheelbase | 5347mm | 5647mm | 5647mm |
| Engine model | CUMMINS, 6BT5.9 | CUMMINS, 6BTA5.9 | CUMMINS, 6CTA8.3 |
| Engine power | 97kw/132hp | 132kw/180hp | 160kw/220hp |
| Overall dimension | 8270*2495*3390mm | 8605*2695*3420mm | 8270*2495*3390mm |
1. Power configuration is Cummins Diese Engine inter-cooling supercharged diesel endine with strong power and reliable performance.
2. Torque converter and power-shift gearbox introduced from GERMANY ZF inc. are integrated together Six forward gears and three backward gears meet various requirements during machine’s working and transporting.
3. Driving axle with integrated free-wheel anti-slip differential and strong roller chain drive tandem case, Boxed oscillated steering front axle with leaned wheels.
4. Popular working mechanism with pendulum-arm connecting rod structure,Standard equipped free-maintenance rolling-plarecircle device. Double cylinders of the blade tip control can adjust the cutting angle depending on soil quality.
5. Flexible hydraulic control system with two sets of HUSCO five way control valve, lmported hydraulic equalizing valve for the bladelifting,Patent hydraulically-operated pin drawing device is designed firstly in board.
6. Steering system with center articulated joint and tilting turning front wheels can get offset travel of the entire machine.
7. Service braking system of,caliper disc brakes on four rear wheels and mechanical internal expanding parking brake let.
8. Hydraulically operated with entire instrumental monitoring system, Free-maintenance OPTIMA.
9. It is optional for front bulldozing plate and rear ripper.
