CE Discount price 3D Profitable CNC Wood Carving Machine

ر.س24,109.47

Clear
Qty:
Compare

Request quotation for: CE Discount price 3D Profitable CNC Wood Carving Machine

Company Information

 Jinan Tian Jiao Machinery Manufacture Co.,Ltd. is specialized in developing and manufacturing Mechanical CNC router (woodworking router, advertising router, stone engraving router), CNC Laser machine, Plasma cutting machine, cutting plotters, metal mould engraving machine and other cnc machines. We supply global market the high quality CNC equipments. We are leading company in this field and being confident in offerring the best service and best quality.



We also could customerized the goods, also could offer OEM servie. Our products has been exported to many oversea countries and gaining more clients satisfaction and good comments.



Hoping that we could be your good and long term honest partner, wish you could get the joyness and satisfaction with our products and service.








1218 CE Discount price 3D CNC router , Wood cutting machine for solidwood, MDF, aluminum, alucobond, PVC, Plastic, foam, stone

wood router (3).jpg

SPECIFICATION:

1. Structure: Integral cast frame, solidity and stable.

2. Accuracy: Adopt High precision Square Guid Rail and imported high accuracy imported ball screw to ensure more stable movement and high accuracy.

3. Appearance: Aluminum decorative appearance, beautiful design and then makes

the whole machine magnificently.

4. Spindle: Advanced water-cooling brushless spindle, low noise, more power, long-time mass processing.



5. The three axes adopt dust protector; ensure the equipment with long service life.

6. Design: It adopt several kinds of electrical parts with good design to minimize the failure ratio.

7. Multi-functions:  It can support  ArtCAM/ Ucancam and several kinds of CAD/CAM design software.



APPLICATION:

This machine is widely used in advertising industry, such as sign making, breast card, office board ,ruler, art crafts, small metal sign plate, construction models and so on.

Efficient manufacturing of wooden products, advertising billboard, acrylic cutting, letter mold form-ling and mass cutting. Also the machine can engrave on iron, brass, aluminum, plastic and wood boards and other non-metal materials.

TECHNICAL DATA

NO.

Description

Parameter

1

X,Y,Z Working Area

1200X1800x150mm

2

Table Size

1520x2250mm

3

X,Y,Z Traveling Positioning Accuracy

±0.03/300mm

4

X,Y,Z repositioning Positioning Accuracy

±0.05mm

5

Lathe Structure

Cast structure

6

X, Y Structure

Shaft Linear Bearings and Ball Screw

7

Z Structure

Ball Screw

8

Max. Consume power

3.0Kw

9

Max. Speed

0-12000mm/min

10

Max. Working Speed

0-8000mm/min

11

Spindle Power Motor

1.5kw water-coolant spindle (2.2KW optional)

12

Spindle Speed

0-24000RPM

13

Drive Mode

Stepper Motor

14

Working Voltage

AC220V/380V, 50/60Hz

15

Command

G code, *uoo, *mmg, *plt

16

Operating System

NC-STUDIO Control system(Mach3,DSP optional)

17

Interface

USB

18

Flash Memory

128M

19

Collet

ER20

20

X,Y Working Delicacy

<0.01mm

21

Software

Ucancam V9,  Artcam

22

Running circumstance

Temperature: 0~45 Relative humidity: 30%~75%

23

Packing Size

1800X2600X1450mm

24

Net Weight

750KG

25

Gross Weight

950KG

Samples Show

2 (2).jpg7.jpg397401398_091.jpg4.jpg

Related Products

Other different configurations wood cnc routers



cnc routers 1cnc routers 2

cnc routers 3

Our Services

QQ20171201101309

Pre-sale service

We offer free detailed quotation and product description.

24 hours online consultation.

Patient introduce and professional suggest buying selection.

Take pictures and make videoes with your done machine.

Strict test and debug machine quality before shipping.

After-sale service

To provide clients with all aspects of after-sales service.

Our company promises:

One year free warranty for the whole machine , lifelong maintenance.

Customer response service time within 12 hours.

After the expiry of the warranty , we continue supply life-long maintenance services.

After the expiry of the warranty , still to provide a wide range of software and hardware support , enjoy free lifelong upgrades . And supply the parts at agent price.

Warranty

The engineers of the original factory are available to do all kinds of the original factory are available to do all kinds of oversea machinery service. In some countries, we have oversea agents doing after-sale service in time and professionally.

we also  offer 24 hours heart to heart service on-line or mobile.

Your technologists could attend the training in our factory and on-line which be free of charge.

The warranty of CNC lathe  is 12 months, small broken parts could be freely replaced at any time, spare parts are delivered with machine for customer convenience.

We offer you best agent price and distributer price for our further cooperation. .

we can offer special custom-made according to your request.

Packaging & Shipping

packing

Inside Packing

  • Use professional Stretch Film to cover the whole lathe
  • Stretch film package with foam protection in each corner.

Outside Packing

  • Sandard export wooden cases and pylwood cases
  • Save space as much as possible for container loading.

Transport

  • We support shipping, air, land and express
  • You can choose the most suitable way of transport

If you have any special request for packing, we can do it.

FAQ
Q1: How to choose a suitable machine?
       You can tell us the working piece material, size, and the request of machine function. We can
       recommend the most suitable machine according to our experience.
Q2: This is the first time I buy the machine, is it easy to operate?
       We can provide the operation manual or video for guiding. If it is hard for you learning, we can
       also help you by “Team viewer”online, with telephone or Skype explain.
Q3: Can you customize the machine for me?
       Yes, we provide customized solution, but considering the cost, we will recommend the
       standard configuration to you first.
Q4: What is the guarantee? In case the machine break down?
       The machine has 1 year guarantee, fail parts will be replaced for free if the machine under
       “ normal operation”.
Q5: How about the documents after shipment?
       We will send all the documents by air after shipment. Including packing list, commercial
       invoice, B/L, and other certificates required by clients.
Q6: Delivery time?
       For standard machine, it would be 7-10 working days; for non-standard machine, it would be
       20 – 30 working days.
Q7: How is the payment?
       Normally we accept T/T or L/C, if you like other terms, tell us in advance.
Q8: Do you arrange the shipment for me?
       For FOB or CIF price, we will arrange shipment for you, for EXW price, you should arrange
       the shipment by yourself.
Q9: How is the packing?
       Step1: water proof wrapping film with foam protection in each corner.
       Step2: Solid seaworthy wood box package with steel belt.
       Step3: Save space as much as possible for container loading.
Model Number

TJ-1218
