Model
|
Working Size
|
Dimension
|
Weight
|
Z Axis Stroke
|
|||
0604
|
600*400mm
|
1360*920*1070mm
|
200kg
|
optional
|
|||
0906
|
900*600mm
|
1450*1100*1070mm
|
320kg
|
optional
|
|||
1309
|
1300*900mm
|
1960*1730*1120mm
|
400kg
|
optional
|
|||
1325
|
1300*2500mm
|
3530*2180*1270mm
|
850kg
|
optional
|
|||
1610
|
1600*1000mm
|
2160*1700*1100mm
|
560kg
|
optional
|
|||
Series
|
CO2 Cutting&engraving Machine
|
||||||
Laser Power
|
60w/80w/100w/130w/150w/180w/200w
|
||||||
Engraving Speed
|
0-1000mm/s
|
||||||
Min Engraving Size
|
English Letter:1.0mm*1.0mm
|
||||||
Highest Scanning Precision
|
4000DPI
|
||||||
Cutting Speed
|
0-1000mm/s
|
||||||
Cutting Thickness
|
0-30mm
|
||||||
Positioning Accuracy
|
≤0.1mm
|
||||||
File Format
|
DST/DXF/AI/PLT/BMP/CDR,etc
|
||||||
Cooling Way
|
Water Cooling
|
||||||
Drive System
|
Leadshine Stepper Motor+Stepper Driver
|
||||||
Machine Structure
|
Covered and protected
|
||||||
Power Supply
|
110V/220V,50HZ/60HZ
|
||||||
Working Environment
|
Temperature:0-45,Humidity 5-95%
|
Materials
|
Engrave
|
Cut
|
Materials
|
Engrave
|
Cut
|
Wood
|
|
|
Wood Veneer
|
|
|
Acrylic
|
|
|
Fiberglass
|
|
|
Cloth
|
|
|
Plastic
|
|
|
Leather
|
|
|
Cork
|
|
|
Paper
|
|
|
Corian
|
|
|
Delrin
|
|
|
Marble
|
|
|
Mat Board
|
|
|
Anodized Aluminum
|
|
/
|
Melamine
|
|
|
Painted Metals
|
|
/
|
Mylar
|
|
|
Tile
|
|
/
|
Pressboard
|
|
|
Glass
|
|
/
|
Rubber
|
|
|
Coated Metals
|
|
/
|
Twill
|
|
|
Ceramics
|
|
/
|
Power
|
60W
|
80W
|
100W
|
130W
|
150W
|
wood
|
5.5mm
|
8.5mm
|
10.5mm
|
11.5mm |
13.5mm |
plywood
|
4.5mm
|
8.5mm |
10.5mm |
11.5mm |
13.5mm
|
leather
|
2.5mm
|
3.5mm |
4.5mm |
5.5mm |
6.5mm |
acrylic
|
9mm
|
13mm |
17mm
|
20mm |
23mm |
pvc
|
2.5mm
|
3.5mm |
4.5mm
|
5.5mm |
6.5mm |
pleixglass
|
3.5mm
|
7.5mm |
9.5mm |
11.5mm |
14.5mm |
plastic
|
1.5mm
|
2.5mm |
3.5mm |
4.5mm |
5.5mm |
rubber
|
1.5mm
|
2.5mm |
3.5mm |
4.5mm |
5.5mm |
fabric
|
1.5mm
|
2.5mm |
3.5mm |
4.5mm |
6.5mm |
bamboo
|
1.5mm
|
2.5mm |
3.5mm |
4.5mm |
5.5mm |
paper
|
0.5-5mm
|
0.5-5mm
|
0.5-5mm
|
0.5-5mm
|
0.5-5mm
|
This co2 engraving and cutting series products adopt imported proprietary sliding guide,and equip with auxiliary facilities,such as blower, exhaust fan, infrared, foot pedal and other auxiliary facilities.Also,this series products integrate advanced high-speed continuous curve motion control card, and adopt self-developed high-speed laser engraving & cutting controlling software.
Application Industries
Laser Engraving cutting machine has been widely used in the fields of plexiglass, architectural models, rubber plates, bamboo products.For cutting and carving on plexiglass products, acrylic art & crafts panel, lenses, wood &cutting carving, advertising materials, crystal characters, easel, packing boxes, models, toys and furnitures etc.
Advantage
1. We use ball screw rod to make the up and down table, which ensure its long-term using and precision. While other company may
have less precision, and will be noise after a period using.
2. We use American IIV company’s reflect mirror and focus lens, which prolong the lifetime of the spare parts.
3. For laser tube, we use the Chinese top brand laser tube, have very stable performance, lifetime can reach 3000 hours. Also, we
have another brand laser tube with 10000 hours lifetime if you require, we can use it in our order.
4. For water chiller, we use both CW5000 for single head, and CW5200 for double head laser machine.
5. All the machine are use red pointer and auto focus system.
6. All the machine have LCD offline control system + USB port.
7. The bearing we use Japan import brand, which ensure the long time performance and accuracy.
8. the transforming belt adopt the famous FULONG brand, it have the metal in the material, so it is fasten and not easy to loosen.
9. All the power supply and laser device are will be running for at least 48 hours testing to ensure it’s good performance.
Applicable Industry: 1. Engraving beautiful patterns and words such as wood, bamboo. Ivory, bone, leather, marble, shell. 2. Mainly used in large plastic character cutting, color plate engraving and cutting, sign engraving, crystal engraving, trophy engraving, authorization engraving etc. 3. Leather clothing processing industry: can engraving and cutting complex patterns on genuine synthetic leather, woolens, clothing ,furnishing, glove, handbag ,model and Aircraft Model, etc.


























Q1: How do I know which model is suitable for my product application?
You just need to tell us the following information then we can offer you a suitable solution? In addition, you can also send us the sample and we will arrange professional engineers for proofing evaluation
1) What is your product? material? thickness? required accuracy?
2) What is the current production process?
3) What is your desired budget and delivery time.
Q2: When I get this machine, but I don’t know how to use it. What should I do?
We will send teaching video of both installation and operation, as well as the English manual. If you have further questions, we have engineers who can speak English can serve you on-line directly. And for some countries , like in India, Malaysia, Korea,Spain, we have local support team, more countries will be in the picture soon.
Q3: How can I do if the machine goes wrong?
We guarantee machine quality for 13 months, during this period, if spare parts of the machine were not man-made damaged, we can send the component to the customer in best delivery. Besides guarantee period, we still provide you free online services for life.If parts broken, you can order replacement parts from us.
Q4. Can you customized product according to different application?
Yes, Dapeng laser is very dedicated to combine with our current ability with the main leading supplier to offer you the customized application.
Q5:What if there are gaps in my product which need to weld?
For laser welding machines, we are usually equipped with automatic wire feeding system. For products with gaps, you can use wire feeding mechanism for wire filling welding
Q6. What is your normal lead time?
Generally standard machine, our lead time is 2-7 days after PO confirmed. Customized product need a little longer.
Q7. Will the package damaged during transportation?
Our package is considerate all the damage factors and make it to be safe, and our shipping agent have full experienced in safe tranportation. We have exported to 80 countries worldwide. So please don’t worry, you will receive the parcel in good condition
Q8:Why should I choose DAPENG LASER compared with other companys?
We are factory with 453 employees, turnover reached 100 millions USD in 2021, ISO 9001 certificated and most products are CE/SGS approoved, can offer you a high-quality pre-sale, in-sale and after-sales solution.
