Best Selling 100-200kg/HR Small Capacity Generator Steamed Rice Cakes Boiler Gas Boiler
Application in Food Industry:
Food Factory, beverage plants, meat plants, breweries, bakeries, baking machine, dishwasher, pasteurized milk, emulsifier, emulsion pot, sugar pot, cooking pot, soup pot, stone fish, porridge, beverage sterilization, steamed buns, steamed buns, steamed, steamed rice, steamed rice cakes, cooked milk, boiled tea, boiled pork, steamer, steamer, heating curd machine, soybean milk machine, single door steaming box, steamed rice box two-door, three steamed rice boxes, canteens disinfection tableware sterilization, disinfection cabinet, single cabinet door disinfection, packaging machines, sandwich pot, storage tanks and other ancillary thaw;
Advantage of Steamed Rice Cakes Boiler Gas Boiler
Automatic LCD intelligent control system
1.,Safety and Science :with a safety valve, pressure controller, water level control protector,
2,multiple chain protection device, safe and reliable.
3,Choose imported Italian burner, burning more fully, more stable operation and lower noise.
4,High quality parts adopt domestic famous brand Delixi electric appliance
5,High Quality Steam Rapidly
6,Easy to install and operate
7,the boiler thermal efficiency above 93%
8,Product quality ensured by :Hydraulic teat ,X-ray ,non-destructive test .
|
Technical Parameter of Steamed Rice Cakes Boiler Gas Boiler
|
||||||||
|
Type/Spec
|
LSS0.1-0.8-Y/Q
|
LSS0.2-0.8-Y/Q
|
LSS0.3-0.8-Y/Q
|
LSS0.5-0.8-Y/Q
|
||||
|
Rated Evaporation (kg/h)
|
100
|
200
|
300
|
500
|
||||
|
Thermal Efficiency (%）
|
≥93
|
≥93
|
≥93
|
≥93
|
||||
|
Rated Pressure (MPa)
|
0.8/1.0 (8-10 bar)
|
0.8/1.0 (8-10 bar)
|
0.8/1.0 (8-10 bar)
|
0.8/1.0 (8-10 bar)
|
||||
|
Steam Temperature(℃)
|
175
|
175
|
175
|
175
|
||||
|
0#Diesel(kg/h)
|
6.1
|
12.2
|
18.3
|
30.5
|
||||
|
Coal gas (Nm³/h）
|
17.0
|
34.0
|
51.0
|
85.0
|
||||
|
Natural gas (Nm³/h）
|
7.6
|
15.2
|
22.8
|
38.0
|
||||
|
Liquefied gas (kg/h）
|
5.7
|
11.4
|
17.1
|
28.5
|
||||
|
Product Dimension (mm)
|
880*850*1760
|
960*960*2380
|
1100*1250*2440
|
1200*1500*2650
|
||||
|
Package Dimension (mm)
|
890*860*1770
|
970*970*2380
|
1110*1260*2450
|
1210*1510*2660
|
||||
|
Steam Caliber
|
DN25
|
DN25
|
DN40
|
DN40
|
||||
|
Drain Outlet Caliber (mm)
|
DN25
|
DN25
|
DN25
|
DN25
|
||||
|
Water Inlet Caliber (mm)
|
DN15
|
DN15
|
DN25
|
DN25
|
||||
|
Weight (kg)
|
450
|
700
|
950
|
1200
|
||||
System Drawing of Steamed Rice Cakes Boiler Gas Boiler
Design structure
1,Boiler liner uses internationally advanced three-pass vertical water pipe tubular structure
2,The steam boiler and burner as a whole to design,.
3,Internal built-in steam separator
How to use?
1,Build a boiler house
2,Connection pipes
3,Connection power
4,Operating boiler
LCD Intelligent Controller
Boiler Liner
Brand: Yano
Original: Shanghai, China
Lifespan：10 years
Water Pump
Brand: Aolong
Original: Zhejiang,China
Lifespan：10 years
Material: Brass/Stainless Steel
Temperature Resistance: Up To 120 ℃.
Burner
Brand: Bultur
Original:Italy
Lifespan：10 years
Feature：Stable in Operation, Low Combustion Noise, More Energy Efficient.
Customer Case 200kg Boiler Gas Boiler Installed in Restaurant
