engraving & carving.
* Heavy duty steel wall structure, keep machine with very good stability.
* Adopt disk/linear type automatic tool changer with 8 tools magazine, spindle change tools automatically,no need manual work.
* High z axis design, suitable for large scale three dimensional surfaces machining.
* With a big rotary device, can process different kinds of 3d sculptures,statues,columns.
|
NO.
|
Descriptions
|
Parameters
|
|
1
|
Model
|
TPR-1325
|
|
2
|
Working voltage
|
AC220V, 3Ph, 60Hz (Optional: 380V)
|
|
3
|
Control system
|
DSP A11 control system
|
|
4
|
Control box
|
Independent single-sided control box
|
|
5
|
Spindle
|
7.5kw water cooling spindle
|
|
6
|
Spindle speed
|
0-24000rpm
|
|
7
|
Motor
|
stepper motor(optional: servo motor)
|
|
8
|
Inverter
|
7.5kw Fuling inverter
|
|
9
|
Table surface
|
T-slot working table with water tank
|
|
10
|
Frame
|
New type thicker and bigger heavy duty welded frame and gantry
|
|
11
|
Lubrication system
|
Manual lubrication system
|
|
12
|
Transmission
|
X/Y rack and pinion drive
Z Taiwan TBI ball screw
|
|
13
|
Linear rail
|
ABBA linear square guide #25
|
|
14
|
Software
|
ARTCAM
|
|
15
|
Drive
|
Leadshine 860
|
2.Suitable for cabinets artificial stone, quartz stone countertops and sink.
3.European style edging, and other heterosexual stone, ceramics, glass and ceramic stone drilling, sanding edge down, carving.
4.Countertop polishing for back splash ,former anomalous edge, cutting and polishing water tap hole through the automatic tools change
5.Processing washing pool and European background wall etc
Whole film packaging machine; anti-collision package edge; fumigation-free plywood wooden box and pallets with iron binding belt.
(2)Shipping:
We cooperate with the company whose experience in the ocean transportation will guarantee your machine safety. We also provide train transport, especially to Russia, Ukraine and other inland countries.
(3)Payment:
We support T/T, VISA, Mastercard payment terms with Alibaba Trade Assurance.
1. 36 months warranty for the whole machine.
2. Technical support by phone, email or WhatsApp/Skype around the clock.
3. Friendly English version manual and operation video CD disk.
4. Engineer available to service machinery overseas.
Our factories are located in Jinan ,Shandong,China.Welcome to visit our factory.
2. Have you exported to our country?
More than 14 years rich experience in producing saling and service ensures you high quality machine and perfect service. Our Export Percentage reach to 90%~95%.We have CE,ISO,FDA,SGS certificates,have exported to
Europe,South America,Arab,Asia,Russia,Spain,Australia and many other countries.
3.How to choose proper my machine?
1)Your materials——–check the cnc router if can do your work
2)The max thickness the materials need to be cut or engrave—–Choose the spindle
3) The max size of your materials—–Choose the working area of the machine.
4. How to protect my order?
You can make the payment by Alibaba Trade Assurance to protect your order.
Trade Assurance is a free payment protection service for buyers.The service is offered by participating suppliers, and is designed to protect your payment if your order is not shipped on time, or if the pre-shipment product quality(optional) does not match the terms agreed on your contract.Your payment is protected up to 100% of an amount -agreed between you and the supplier.
5.How to transport and pack?
The machine will be packed in fumigation wooden box.
For big machine,it is the best reasonable way to be transported by sea or rails.
The price terms: EXW,FOB,CIF,Door to Door and so on.
6. If machine have any problem after I receive it, how can I do?
Pls contact us by Email or Skype ,Wechat or Phone number. We will reply you as soon as we see your message
If there has any quality problem during the 3 years warranty period.the parts of the machine shall be changed free of charge (non-human damage).
|
