Batch Code Inkjet Printer with Conveyer Belt Qr Code Online Inkjet Printing Machine

Shape features

10.1 Inch Capacitive Screen, Aluminum Print Head,The USB Interface

Dimension

250*158*35mm

Net weight

0.45kg

Nozzle

TIJ Hot Foaming Nozzle

Operating system

Linux3.4

Character type

high-definition printing character, dot matrix font, Simplified, Traditional Chinese and English

Printing line

1-30 lines (adjustable)

Printing height

1.2mm-140mm

Single heads 12.7mm

Single heads 25.4mm

12.7mm*2heads,25.4mm*2heads

12.7mm*3heads,25.4mm*3heads

12.7mm*4heads,25.4mm*4heads

12.7mm*5heads,25.4mm*5heads

12.7mm*6heads,25.4mm*6heads

( max 10 heads You can choose the printing suitable heads according to your demand)

Print code

bar code, QR Code

Code type

Code128,code39,int25,upca,qr code

Printing distance

1-10mm Mechanical Adjustment (the best distance between the nozzle and printed object is 2-5mm)

Automatic print

date, time, batch number shift and serial number, etc

Printing speed

60m/min

Language

Chinese,English,French, Russian, Japanese, Spanish, Korean, Thai, Arabic, Portuguese

Ink type

Quick-dry solvent environmental ink, water-based ink and oily ink

Ink color

black, white, red, blue, yellow, green, invisible

Ink volume

42ml(usually can print 800,000 characters)

External interface

Power and optoelectronic interface, DVI Cable Interface, USB Interface

Adapter Parameters

100-240V AC Input

Print Library

Synchronous Machine Library

Spray Printing Precision

300-600 DPI

Information is Stored

3GB

Printing material

board, carton, stone, pipe, cable, metal, plastic product, electronic, the fiber board, light steel keel, aluminum foil, etc.
