Product Overview
Automatic hydraulic thread rolling machine
The thread rolling machine is mainly used for rolling workpieces of various specifications for building wall thread, top drag,trapezoidal thread and modular thread. It has the advantages of simple operation and high efficiency. This machine is mainly used for rolling various external threads, including ordinary threads, trapezoidal threads and modular threads. It can also be
used for hydraulic processing such as forming, straightening, calendering and knurling of workpieces.
used for hydraulic processing such as forming, straightening, calendering and knurling of workpieces.
FEATURES AT A GLANCE
Thread rolling machining is a multifunctional cold extrusion forming machine tool, which can roll various external threads,including ordinary thread type teeth and modular threads. It can also perform rolling processing such as forming,
calendering and rolling on the workpiece. There are manual control pedal control, semi-automatic control and automatic control.With the corresponding rolling wheel, it can process a variety of types of ordinary bolts and various special-shaped bolts.
It is widely used in hardware, electric power, rail transit, automobile and motorcycle accessories, construction and
other fields.
other fields.
PRODUCT SPECIFICATIONS
|
Product parameters
|
||
|
Product brand
|
QIJI
|
|
|
Product model
|
QJ-Z28-150
|
|
|
Diameter
|
Φ68mm
|
|
|
Pitch
|
7.5mm
|
|
|
Angle Main axis
|
±5°m
|
|
|
Maximum roll pressure
|
168KN
|
|
|
Rpm Main axis
|
34 49 66 82rpm
|
|
|
External Diameter of Rolling Die
|
Φ120-170mm
|
|
|
Rolling die aperture
|
54mm
|
|
|
Maximum Width
|
100mm
|
|
|
Spindle drive power
|
7.5KW
|
|
|
Hydraulic Power
|
2.2KW
|
|
|
Dimensions
|
1550*1450*1520mm
|
|
|
Weight
|
1850kg
|
|
Product display
PRODUCT CONFIGURATION
