Name: Automatic Loose Fill Packing Peanut Extruder Foam Packing peanuts Making Machine
SKU: 211895412019181
Availability: InStock

Automatic Loose Fill Packing Peanut Extruder Foam Packing peanuts Making Machine

ر.س23,098,530.47

Product Description

Biodegradable foam filling Packing Peanuts extrude making machine with CE

Eco Starch Based Packaging Foam are widely used in express cartons, children’s toys and other fields. Because of its novel shapeswhen exposed to water, various colors, strong protection of products, melting in water, rapid explanation, no pollution, and harmless to humans if ingested, the market demand is increasing day by day.It can well protect precision instruments and various electrical products, and play a role in shock absorption.As a children’s toy, through different color matching, children’s creativity and imagination can be exerted.

Our Eco Starch Based Packaging Foam Processing Extruder Machine is kind of new application of extrusion technology can use starch as raw material to produce degradable foam fillings. The machine is simple to operate, low investment, quick return, small footprint and low power consumption. Manufacturers who have demand for environmentally friendly products are welcome to negotiate business.This machine can make modified starch ,denatured starch,pregel starch and degradable packing material by changing different designed barrel and screws of double screw extruder.It is widely used in textile ,food process,oil drilling,paper,packaging and transportation etc.

Model	HM65	HM70	HM85
Installed Power	77kw	108kw	150kw
Power Consumption	50kw	75kw	100kw
Capacity	120-150kg/h	220-260kg/h	400-500kg/h

Sample

Detailed Images

Mixer

Dimension(m): 1.1×0.8×1.4
Motor Power: 4KW

Speed: 400rpm
Throughput: 30kg per loading (5-6 minutes per loading)
Functions:Mix powder raw material with water
Features:
1. stainless steel material(1.5mm).
2. new handle-opened design of discharge holes,no material leak
3.High speed can mix material better than other slow mixer..

Screw Conveyor

Dimension(m): 3.2×0.6×0.7
Motor Power: 1.1KW
Screw speed: 300rpm
convey height range:1.5~2.5M
barrel diameter: Φ141mm
Function:
Power material can be conveyed in the stainless steel roller to the feed machine of extruder without leaking, dust and pollution;

Twin-screw Extruder

Dimension(m): 2.6×1.0×1.3

Total power: 37kw

Main Motor Power:22KW

Feeder motor:0.75kw

Cutting motor: 1.5kw

Heating power:10kw

Extruder diameter:Φ65 mm

Function:

Extrude and cook raw material into different size and shapes

Features:

Screw material is 38CrMoAl with nitriding treatment, the hardness is 60HRC.. The barrel also use good material, hardness is 55HRC.

The gear box has forced lubrication system.

All motors can be adjusted the speed by Inverter.

The Extruder can change different molds to produce different Shapes product.
