Auto motor brushless screwdriver electric screwdriver brushless for mobile phone repair

ر.س696.09

Clear
Qty:
Compare

Request quotation for: Auto motor brushless screwdriver electric screwdriver brushless for mobile phone repair

Auto motor brushless screwdriver electric screwdriver brushless for mobile phone repair



product description





7) GH-10L/PL/PLK|GH-15L/PL/PLK|GH-20L/PL/PLK/GH-25L/PL/PLK



Two start mode: Lever start and push start

It is specially designed fro screw fasten automation equipment with signal output



With imported brushless motor, it runs very stable, long life, and excellent performance



Low vibration, noise, and electromagnetic interference, it fits environmental request, especially for dustfree working room.



The internal stop device adopts magnetic induction system, it owns high sensitivity, short braking, low impact force, and it is not easy to be broken after being used a long time.



The newest power supply design, very light and compact, it fits 100-250V voltage



The three core power cord adopts silicon material with anti-hardening function and long life feature



The torque setting is very precise, it is suitable for mobile phone, digital camera, and other high accuracy electric products



The shape is designed according to ergonomics, the shell is made of number one class PC material, it is small body, light weight, with resistance to impact, it will not be tired after worker uses it a long time, the working efficiency is improved too much



Model No

GH-10L/PL/PLK

GH-15L/PL/PLK

GH-20L/PL/PLK

GH-25L/PL/PLK

Input voltage



DC-30V

Torque Range

Kgf.cm

1-10

2-15

3-20

5-25

  Lbf.in

0.868-8.68

1.74-13.02

2.6-17.36

4.34-21.7

  N.m

0.098-0.98

0.2-1.47

0.29-1.96

0.49-2.45

Torque accuracy

+/-3%

+/-3%

+/-3%

+/-3%

Torque adjustment

stepless

stepless



stepless

Torque adjustment mode

Back stop screw/internal adjust

Backstop screw/internal adjust

Back stop screw/internal adjust

Back stop screw/internal adjust

Start mode

Lever/push start

Lever/push start

Lever/push start

Lever/push start

Speed without loading r.p.m

0-1200 1800 for PLK

0-1200 1800 for PLK

0-1200 1800 for PLK

0-1200 1800 for PLK

Weight (g)

445

445

445

445

Current without load

0.3A

0.3A



0.3A

Bits

¢4/¢5/H6.35

¢4/¢5/H6.35

¢4/¢5/H6.35

¢4/¢5/H6.35

Screw type

Mechanical tooth

1.6-3.0

2.3-3.5

2.6-4.0

2.6-5.0

Self-tacking tooth

1.6-2.6

2.0-3.0

2.0-3.5

2.6-4.5

Feature:

1.Imported brushless motor, strong performance, high stability and long service life.
2.Low vibration, low noise, low electromagnetic interference, comply with environmental requirements, especially 3.applicable to dustfree working environment.

4.The internal stop device adopts magnetic induction system, with high sensitivity, instantaneous braking, low impact force, and long-term use not easily damaged.
5.The newest power supply design, break through the traditional volume big, the power consumption big drawback, use medium is lighter, more convenient, apply to 100V ~  250V working environment.
6.The power line is designed with silicon wire anti-hardening three-core wire, and the service life is too long.
7.The torque is accurate, the torque is accurate and the torque is adjusted by using professional tools so that you don’t have to worry about the torque.
8.The outer type is designed according to ergonomic grip, and the shell is made of high-grade PC material, which is of exquisite volume, light weight, impact resistance,  comfortable use, easy to use for long time, and improve production efficiency.
9. A perfect combination of push-start and push-down dual mode functions, with just a small switch to make your use more arbitrary.
10. Specially designed for screw assembly automation equipment, with signal output, is the best choice for the manufacturer of screw assembly automation equipment.
11. The speed of 0-1200rpm can be adjusted to suit your different needs.
12. The products are fully functional and meet all kinds of industrial needs.
