Mini cnc wood router price for sale
Featyure of mini cnc router:
1. The whole machine adopts robust structure,it’s stability.
2. Z axis use ball screw,it’s stable running,precision and high efficiency .
3. With Mach 3 control system,high precision,econonmic and durable.
4. Water cooling spindle prolong machine life and help to maintain high quality dowm for clean cuts.
5.A variety of sizes models is available to choose.
6.Can change the parts according to your requirements.
get more other cnc machine information
Technical parameter of mini cnc router:
|
ITEM |
3040 CNC ROUTER |
OPTIONAL PARTS |
|
X Y Z Working area |
300*400*200mm |
Other size is optional |
|
Table size |
400*540mm |
|
|
X,Y,Z Traveling Positioning Accuracy |
±0.01/300mm |
|
|
X,Y,Z Repositioning Accuracy |
±0.01 mm |
|
|
Table Surface |
T-slot, hold the material by clamps |
vacuum table |
|
Machine body |
Iron |
|
|
X,Y axis driving way |
Rack and Pinion /Linear square guide rails& Blocks imported from Taiwan, HIWIN brand |
|
|
Z axis driving way |
Ball screw / Linear square guide rail and blocks imported from Taiwan, HIWIN brand |
|
|
Max. Power Consumption |
2.0kw(without spindle) |
|
|
Max. Rapid Travel Rate |
33,000mm/min |
|
|
Max. Working Speed |
25,000mm/min |
|
|
Spindle Power |
800W water cooling spindle |
Italy HSD or Chinese air cooling spindle |
|
Spindle Speed |
0-24000 RPM |
0-18000RPM |
|
Inverter |
Fuling |
Yaskawa, Panasonic,Delta or others |
|
Working Voltage |
AC220V/50HZ |
|
|
Command Language |
G Code |
|
|
Control system |
Mach 3 |
Ncstudio, DSP, Syntec or others |
|
Computer Interface |
USB |
PCI |
|
X,Y Resolution |
< 0.01mm |
|
|
Software Compatibility |
Type3/ Artcam Software) |
|
|
Dust collector |
2.2KW with 2 bags |
3KW/4KW |
|
Running Environment Temperature |
0°-45° |
|
|
Relative Humidity |
30%-75% |
|
|
Packing Size |
400*450*350mm |
|
|
Net weight |
80kg |
|
|
Gross weight |
90kg |
|
Detail image of mini cnc router:
get more other cnc machine information
Application of mini cnc router:
1. Woodworking industry:wood crafts,picture frames cutting,handicraft carving wave plates,wooden door production and processing.
2. Advertising industry:advertising materials such as PVC,acrylic,double color plate.
3. Stone working industry:such as natural marble,granite,artificial stone,tombstones,milepost,ceramic tile,glass and other materials.
4. Metal industry:carving aluminum,copper,stainless steel and so on.
Production Process:
