ANENG AN860B+
Digital Professional Multimeter
Digital Professional Multimeter
A.Introduction:
AN860B+ is battery-powered,true-rms,auto-ranging digital multimeter,with a 6000 counts,LCD display and backlight.
AN860B+ is battery-powered,true-rms,auto-ranging digital multimeter,with a 6000 counts,LCD display and backlight.
B.Electrical Specification:
|
Function |
Range |
Accuracy |
|
DC Voltage(V) |
6V/60V/600V/1000V |
+-(0.5%+3) |
|
DC Voltage(mV) |
60mV/600mV |
+-(0.5%+3) |
|
AC Voltage(V) |
6V/60V/600V/750V |
+-(1.0%+3) |
|
AC Voltage(mV) |
60mV/600mV |
+-(1.0%+3) |
|
DC Current(A) |
6A/20A |
+-(1.2%+3) |
|
DC Current(mA) |
60mA/600mA |
+-(1.2%+3) |
|
DC Current(uA) |
600uA/6000uA |
+-(1.2%+3) |
|
AC Current(A) |
6A/20A |
+-(1.5%+3) |
|
AC Current(mA) |
60mA/600mA |
+-(1.5%+3) |
|
AC Current(uA) |
600uA/6000uA |
+-(1.5%+3) |
|
Resistance |
600Ω/6kΩ/60kΩ/600kΩ/6MΩ |
+-(0.5%+3) |
|
60MΩ |
+-(1.5%+3) |
|
|
Capacitance |
9.999nF |
+-(5.0%+20) |
|
99.99nF/9.999nF/9.999uF/99.99uF / 999.9uF |
+-(2.0%+5) |
|
|
9.999mF |
+-(5.0%+5) |
|
|
Frequency |
99.99Hz / 999.9Hz/9.999kHz/ 99.99kHz/999.9kHz/9.999MHz |
+-(0.1%+2) |
Diode:Yes
Continuity Test:Yes
Temperature:Yes
Continuity Test:Yes
Temperature:Yes
C.Package:
1 * ANENG AN860B+ Digital Multimeter
1 * Test lead wire
1 * Thermocouple
1 * Manual
1 * Storage Bag(According to the choice)
1 * Combination line(According to the choice)
1 * ANENG AN860B+ Digital Multimeter
1 * Test lead wire
1 * Thermocouple
1 * Manual
1 * Storage Bag(According to the choice)
1 * Combination line(According to the choice)
