Product Description
ECJET is high resolution printer with touch screen developed on HP print tech, featured as high resolution and high print speed. It can control 1-8 print heads. It can print variable data including text, batch number, manufacture& expiry date and image, matching with various kinds of production lines
(Silver / blue optional)
With a 7 inch touch screen as controller, can edit directly, easy to use.
* Maximum support 8 print heads, can combine or separate freely according to print requires
* High system integration, small in size, less component, easy install and maintenance
* Metal shell, industrial design, which makes printer more stable
* Non-contact RFID lock system, which makes it more stable to read the cartridge.
* It supports to print database with text and barcode.
Size Information
|
Model
|
ECJET
|
||
|
Printing System
|
HP TIJ 2.5
|
||
|
Print Height
|
EC-1
|
12.7mm （1 printhead is 12.7mm）
|
|
|
EC-11
|
2*12.7mm
|
||
|
EC-111
|
3*12.7mm
|
||
|
EC-1111
|
4*12.7mm
|
||
|
EC-2
|
25.4mm
|
||
|
EC-21
|
25.4mm+12.7mm
|
||
|
EC-22
|
2*25.4mm
|
||
|
EC-4
|
50.8mm
|
||
|
Max Printing Speed
|
38m/m@600×600DPI ,76m/m@600×300DPI
|
||
|
Interface
|
USB、Network port
|
||
|
Display
|
7 Inch
|
||
|
Print Data Type
|
Text、Barcode、QRcode、Variable Date、logo
|
||
|
Code Type
|
EAN8、 EAN13、 EAN128 、CODE25、 CODE39、 CODE128、 CODE128A、CODE128B、CODE128C、Codebar2width 、UPC12 、PIATS 、 PDF417 、PIATSDRUG 、 QRCODE
、 DATAMATRIX
|
||
|
Other
|
Analog speed printinganalog electric eye printing
|
||
|
Power
|
110-220VAC 50/60Hz
|
||
|
Max Power
|
120W
|
||
|
Operating Temperature
|
Temperature 5℃～35℃ Humidity 10%～90%
|
||
|
Packing Dimension
|
450*350 *150 mm（L*W*H）
|
||
Details Images
1、7 inch Hand Touch Screen 2、1 or 8 printer headS
3、 Photocell 4、Encoder（If to purchase extra if needed）
Encoder port: The function of encoder is to detect speed of print object, and make print
speed as same as object speed. Whenuser install and adjust encoder incorrectly, print
imagemay distort.
imagemay distort.
Sensor port: When sensor detects a print object, it will send a trigger signal to printer,
and printer will control print head to print according to signal received.
Alarm port:The current print state and error state are reflected by alarm.
Industry Application
EC series packaging coding system, mainly used for printing on packaging, 1D code, 2D code,
production date, serial number, product batch number, etc.
The specific industry applications are as follows:
1.Food industry (paper packaging, film packaging, various biscuits and boxed food packaging, etc.);
2.Building materials industry (various density board, blockboard, solid wood board, asbestos board, wooden floor, etc.);
3.Other industries (bottled paper labels, paper labels on bottles, paper labels on medicine bottles, boutique boxes, etc.)
