A5882-45 Turbine worm gear motor
1-9Rated Voltage: 12v 24v.
1-10Direction of Rotation:CW when viewed from output shaft side
1-11Operating Temperature and Humidity:Temperature range of -10C~+50C,Humidity range of 30%~80%.
1-12Storage Temperature:Temperature range of -20C~+60C
2.Measuring Conditions:
2-1 Motor Position:To be place t horizontally when measuring
2-2 Power Supply: Regulated DC power supply
–No load speed:2-160rpm.
–Robotics, Small Appliance, Fanner, Electric Curtain;
–Medical Pump, Surgery Tools, Medical Stirrer, centrifugal Machine; Electric Valve, Actuator, medical device
–Electric motor,low noise,low current and no spark.
Ratio: 1：30 / 1：50 /1：250/ 1：176/ 1：545
— 555 Motor information : 12V 3000RPM 24V 6000RPM
Remark:
Please confirm the voltage and speed before ordering,if you don’t reply within 8 hours after ordering, we will random send one for this type, hope your kindly understanding.
If you want to need other speed , please contact us , we will make it for you
Hobbing gear team
Reducer
gear reducer
Turbine worm gear motor .
|
A5885-45 Parameter
|
||||||||||||||||||
|
Gear
Ratio 1：00 |
No-loading
|
Rated loading
|
Stall
|
|||||||||||||||
|
Rated
volt |
Speed
|
Current
|
Speed
|
Current
|
torque
|
Power
dc motor |
Torque
|
Current
|
||||||||||
|
v
|
Rpm
|
mA
|
Rpm
|
A
|
KG.CM
|
w
|
KG.CM
|
A
|
||||||||||
|
30
|
24
|
200
|
0.27
|
170
|
2.5
|
20
|
50
|
75
|
12
|
|||||||||
|
50
|
24
|
120
|
0.27
|
102
|
2.4
|
32
|
50
|
120
|
12
|
|||||||||
|
176
|
24
|
34
|
0.27
|
29
|
2.4
|
85
|
50
|
200
|
12
|
|||||||||
|
250
|
24
|
24
|
0.3
|
20
|
2.4
|
100
|
50
|
280
|
12
|
|||||||||
|
545
|
24
|
11
|
0.27
|
9
|
2.5
|
120
|
50
|
ban
|
12
|
|||||||||
