70Mpa Hydraulic Power Pack 40mm Steel Rebar Cold Extrusion Press Crimping Machine Rebar Cold Extrusion Machine
DBDF Series electric pump is a complete hydraulic pump station includes oil pump, control valve, oil tank, motor, oil gauge, etc.
DBDF Series hydraulic power pack can achieve high & low pressure supply and output large flow at the same time. When high pressure, the low pressure pump will automatically return oil without load, reduce the power loss of the motor, also features shutting down with maintaining pressure and reversing under pressure.
Applications:
1. Equipped with oil cylinders or related tools, it can meet the requirements of lifting, bending, straightening, extrusion, shearing, riveting, disassembly, and pressing.
2. Can be used as the hydraulic power pack in some mechanical equipment.
3. Can be used as the pressure test station for various high pressure hydraulic components, high pressure vessels and high pressure hoses.
|
Max Pressure |
Min Pressure |
High pressure flow |
Motor Power |
Voltage |
Capacity of Tank |
|
70Mpa
|
2Mpa
|
1L/min |
0.75kw |
380V/220V or Customized |
14L |
|
2L/min |
1.5kw |
14L/16L |
|||
|
2L/min |
2.2kw |
16L |
|||
|
3L/min |
3kw |
40L |
|||
|
4L/min |
4kw |
50L |
