6oz milk tea plastic cup making machine bag cake cup make machine
YGM-22D middle speed paper cup forming machine adopts the latest technology to make it energy-efficient, economical and durable. The shape is exquisite and the molds can be changed. SiNi will strive continuously to pursue the excellence in science and technology innovation. This paper cup forming machine adopts open cam design, automatic oil lubrication system and PLC control system to improve the machine function and performance.
Technical Parameters
|
Model |
YGM-22D |
YGM-22S |
|
Cup size |
6oz-22oz |
|
|
Raw material |
Single PE coating paper |
Single and double PE coating paper |
|
Paper thickness |
160-280gsm |
160-300gsm |
|
Top mouth diameter |
60mm-90mm |
|
|
Bottom diameter |
40mm-70mm |
|
|
Bottom depth |
5mm-10mm |
|
|
Height |
60mm-180mm |
|
|
Capacity |
60-90 cups per minute |
|
|
Main motor power |
1.5kw |
|
|
Total power |
11.5kw |
16kw |
|
Energy consumption |
6-6.5 kw / hour |
7-7.5 kw/ hour |
|
Air consumption |
0.4m3/min, 0.5-0.8Mpa |
|
|
Weight |
2200kg |
|
|
Dimension |
1750x1350x1850mm 1220x950x2080mm |
1900x1350x2000mm 1220x950x2080mm |
Middle Speed Paper Cup Forming Machine Min. and Max. Cup Size
Paper Cup Packing Machine
Product Features & Pictures Display
1. Open cam transmission system. Unique hanging cam design to reduce pollution.
2. Automatic lubrication system. Save your labor and easier your daily work.
3. Aluminum Mold, longer using life with less abrasion.
4. Ultrasonic unit guarantee fast and good quality sealing.
5. Unique robot hand design. Make sure no transformer of cup body.
6. Circulatory silicon oil lubrication system. Save the usage of silicon oil and keep machine and cups clean.
7. Bottom paper feeding uses servo motor.
8. Using two heaters to heat up the bottom, ensure the bottom sealing and guarantee high speed production.
9. PLC control system
