36KW 51KG/H Vertical Automatic Electric Steam boiler
Product Parameter
| Type/Spec | LDR-0.051-0.8 | LDR0.064-0.8 | LDR0.07-0.8 | LDR0.086-0.8 | LDR0.103-0.8 | LDR0.129-0.8 | LDR0.143-0.8 |
| Electric power(KW ) | 36 | 45 | 50 | 60 | 72 | 90 | 100 |
| Rated evaporation(Kg/h) | 51 | 64 | 70 | 86 | 103 | 129 | 143 |
| Voltage(V) | 380 | 380 | 380 | 380 | 380 | 380 | 380 |
| Rated pressure(Mpa) | 0.8 | 0.8 | 0.8 | 0.8 | 0.8 | 0.8 | 0.8 |
| Steam temperature(°c) | 175 | 175 | 175 | 175 | 175 | 175 | 175 |
| Power wire(mm² ) | 16 | 16 | 25 | 35 | 50 | 50 | 50 |
| Dimension(L*W*H) | 740*570*1440 mm | 840*640*1540 mm | |||||
| Steam caliber (mm) | DN20 | DN20 | DN20 | DN25 | DN25 | DN25 | DN25 |
| Drain outlet caliber (mm) | DN20 | DN20 | DN20 | DN25 | DN25 | DN25 | DN25 |
| Water inlet caliber (mm) | DN15 | DN15 | DN15 | DN15 | DN15 | DN15 | DN15 |
| Weight (kg ) | 180 | 180 | 190 | 230 | 230 | 240 | 240 |
Advantage:
1. Unique Internal Structure Design That Is Exempted from Applying for a Boiler Use Certificate
2. The Use of High-quality Core Components—Electric Heating Pipe
3. Use High-quality Components
4. Multiple Safety Interlock Protection
5. Extremely Easy to Install and Use
6. Scientific Design and Attractive Appearance
7. Use Electricity Is More Environmentally Friendly and More Economical
Application Fields
Washing ironing industry: dry washer , dryer and washing machine , dryer, ironing machine, electric iron, and other ancillary equipment.
Food machinery industry: tofu machine, steam box, sterilization pot, packing machine, coating equipment, sealing machine, such as supporting the use of equipment
Biological chemical industry: fermentation tank, reaction kettle, sandwich pot, mixer, emulsifying machine supporting the use of equipment
Other industries: oil field, car) steam cleaning industry, (hotel, school, dormitory, batch plant) made by hua-dong works are hot water supply, (Bridges, railways) concrete curing, leisure (salon), sauna bath, heat exchange equipment.
One of our Food making company customer buy from us the 36KW electric steam boiler
