item
|
value
|
|
Place of Origin
|
China
|
|
|
Zhejiang
|
|
Brand Name
|
3Q
|
|
Model Number
|
3Q
|
|
Usage
|
Stripping
|
|
Place of Origin
|
Wenzhou, China
|
|
Usage
|
Wire Stripping
|
|
Application
|
Strip wire machine
|
|
Type
|
Wire Cutting Stripping Machine
|
|
Name
|
Automatic Wire Stripping Machine
|
|
Wire Range
|
0-2.5mm
|
|
Electric Wire Stripping Machine
|
Multi function Wire Stripping
|
|
Brand Name
|
3Q
|
|
Function
|
Wire Cut and Strip
|
|
weight
|
28kg
|
|
Mechanical function
|
Wire cutting, single-ended stripping, double-ended stripping
|
|
physical dimension
|
800* 830* 1530MM
|
|
Machine weight
|
315KG (including wooden box packaging)
|
|
Display method
|
Color LCD touch screen
|
|
Operation mode
|
Automatic operation + manual operation
|
|
Knife adjustment metho
|
Electric knife adjustment
|
|
Tool material
|
Sweden ASP60 powder high speed steel
|
|
Pneumatic accessories
|
Original Airtac
|
|
Screw guide
|
Original Taiwan Shanghai Bank
|
|
Cutting tolerance
|
Range of variation 1MM+cut length*0.2% or less
|
|
Cutting length
|
45-9999mm
|
|
Stripping length
|
1.5- 10mm
|
|
Applicable wire
|
AWG18-28#
|
|
Cutting speed
|
6500pcs/hour (within 100MM in length)
|
|
Processing capacity
|
4500 pieces/hour (within 100MM in length)
|
|
Terminal pressure
|
Standard 2.0T (other crimping force needs to be customized) air’ pressure
|
|
air pressure
|
5.0KG (requires stable, dry air)
|
|
Detection device
|
The presence of terminals, wires, crimping detection, air pressure detection, etC.
|
|
Configure power
|
AC220V
|
|
rated power
|
2.5KW
|
Our production factory as under ISO9001 and CE are through whole procedure. All products can be tested for needed certificates with your standard and request, We always adhere to the business philosophy of: Customer First, Service Foremost. We advocate the tenet of “Brand and market in honesty” on the basis of equality, mutual benefit and the exchange of needed goods.
We are based in Zhejiang, China, start from 2014,sell to North America(30.00%),Western Europe(10.00%),Southern Europe(10.00%),Eastern Europe(10.00%),South America(10.00%),South Asia(5.00%),Africa(5.00%),Southeast Asia(5.00%),Northern Europe(5.00%),Oceania(5.00%),Central America(1.00%),Eastern Asia(1.00%),Mid East(1.00%). There are total about 101-200 people in our office.
2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3.what can you buy from us?
CUTTING MASHINE,SHOWS MASHINE,CUPS MASHINE,MASHINE
4. why should you buy from us not from other suppliers?
Wenzhou keerte measurement and testing instrument Co., Ltd., established in 2008, It is a professional company engaged in new energy wire processing equipment,precision three axis dispensing machine,soldering machine,screw machine,non-standard automation a
5. what services can we provide?
Accepted Delivery Terms: FOB,CIF,EXW,FAS,CIP,CPT,DEQ,DDP,DDU,Express Delivery,DAF,DES；
Accepted Payment Currency:USD,EUR,JPY,CAD,AUD,HKD,GBP,CNY,CHF;
Accepted Payment Type: T/T,L/C,D/P D/A,MoneyGram,Credit Card,PayPal,Western Union,Cash,Escrow;
Language Spoken:English,Chinese,Japanese
