Introduction
The equipment for purification distillation test rotates and shapes a thin film in negative pressure condition by heating, evaporates efficiently, and then condenses and recollects solvent to purify and separate.
Feature
- Automatic lifting with easy and quick operation.
- High borosilicate glass 3.3(GG-17), good physical and chemical properties.
- PTFE sealing parts and tight sealing to offer high vacuum and high evaporation rate
Specification
|
Model |
ABTR-03 |
|
Condenser |
Vertical Condenser |
|
Collect Flask |
2L |
|
Rotary Flask |
3L |
|
Motor Power |
60W |
|
Power Voltage |
220/110V for Optional |
|
Bath Power |
1500 W |
|
Bath Volume |
3L |
|
Bath Material |
SS304 Combined Bath Material Completely Closed Heated |
|
Evaporation Rate(Water) |
2.5L/ H |
|
Speed Range |
0 – 180 RPM |
|
Lift and Stroke |
Automatic Control, 120 mm |
|
Glass Material |
GG-17 Glass |
|
Heating Temperature Range |
Rm-99 Degree |
|
Heat Control |
PID |
|
Heat control accuracy |
±1 Degree |
|
Ultimate Vacuum |
0.098 Mpa |
|
Dimensions (W x H x D) |
650×520×650 mm |
|
Weight |
40 k |
Remark: Heating Temperature Range can be extened to 199 Degree.
