Product Description
The structure design of this CO2 RF laser is scientific. The material selection is good. The manufacturing process is advanced. The quality is stable and reliable.
It can be used for laser marking machine, coding machine and welding machine.
Specification
|
Wavelength
|
9.3-10.6μm
|
|
Model
|
T30 T35 T40
|
|
Output Power
|
30W 35W 40W
|
|
Beam Diameter
|
2.5±0.2mm
|
|
Power stability
|
±5%
|
|
Modulated Frequency
|
0-20KHz/0 – 100%
|
|
Cooling Method
|
Fan/water cooling
|
|
Air Flow/Water Flow
|
2Kg/min-3Kg/min
|
|
Beam Divergence
|
<7mrad
|
|
M2 factor
|
<1.2
|
|
Polarization ratio
|
>100:1 Horizontal Polarization
|
|
Electricity Input
|
48VDC/12A
|
|
Dimension
|
360×93×140mm
|
|
Expected lifetime(hours)
|
20000(inflatable)
|
|
Warranty
|
1 year
|
