Product Description
Product Parameter Shanghai Yano Boiler Supplier Low Pressure Steam Boiler
|
||
Product Type
|
YN24-0.7-D
|
|
Electric power (kw)
|
24
|
|
Rated evaporation (kg/h)
|
34.4
|
|
Source voltage (v)
|
380
|
|
Rated pressure (MPa)
|
0.7/1.0
|
|
Steam temperature (℃)
|
170/185
|
|
Power Wire (mm²)
|
10
|
|
Dimension (mm)
|
660*420*1230
|
|
Steam caliber (mm)
|
DN15
|
|
Drain outlet caliber (mm)
|
DN15
|
|
Water inlet caliber (mm)
|
DN15
|
|
Weight (kg)
|
120
|
Main Features Shanghai Yano Boiler Supplier Low Pressure Steam Boiler
1) Unique Internal Structure Design That Is Exempted from Applying for a Boiler Use Certificate
2) High-efficiency Boiler Liner Structure
3) Advanced Automatic Control Function
4) Safe and scientific structural design
5)High-quality and fast steam
2) High-efficiency Boiler Liner Structure
3) Advanced Automatic Control Function
4) Safe and scientific structural design
5)High-quality and fast steam
Specification
LCD Intelligent Controller
Boiler Liner
Water Pump
Packing & Delivery
To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
Company Profie
We are specialized in the design, production, sales and service of small and medium-sized boiler setters. We conduct national quality supervision and inspection with a class C boiler manufacturing license.Our company is located in the economic boom area, northwest of China-Shanghai. Our factory covers an area of 12,000 square meters, including plant and office building covering an area of 8,600 square meters.
With years of continuous development and progress, we have got more than ten inventive patents and many kinds of national energy saving product honors.
We have passed ISO9001international quality management system certification, and obtained the glorious title of "the 2010 WorldExpo in ShanghaiOutstanding Private Enterprises", showing the world the excellent image ofChineseenterprises.Since ourestablishment,we have been supported by the University Of Shanghai for technical research and development.
Our company has the independent research and development ability of fully automatic electric heating steam boiler, electric circulation hot water unit,automatic fuel gas steamboiler, automatic fuel gas hotwaterboiler,business stainless steel cube type electric water heater,hightemperature high-pressure steam cleaning equipment and 20 series of over one hundred kinds ofproducts.
