1t 2t 3t 5t 8t 10t 15t 20t Large Tonnage Hydraulic Winch For Excavator Pulling Wood
Heavy duty single drum planetary reducer 5 10 15 20 ton hydraulic winch adopt two-stage planetary gear transmission, compact structure, smooth operation, more tooth, the transmission efficiency high output torque, widely used in hoisting, transportation, engineering machinery, metallurgy, mining, construction machinery and other fields if delivery status with motor, hoisting mechanism has joined in gear oil, if supply state without motor, users need to join the gear oil before install the motor.
Hydraulic Winch Feature
The full floating planetary gear reducer makes the operation more stable and the structure more reasonable. Adopt multi – plate friction normally closed system. The actuator has high braking torque and safety. The product has the characteristics of small volume, compact structure and high transmission efficiency Has the function of free fly Adopt brand motor, long service life. The mounting bracket can be manufactured separately according to user’s requirement According to the needs of users, the special winch balance valve, shuttle valve. Adopt manual, pneumatic clutch device.
The full floating planetary gear reducer makes the operation more stable and the structure more reasonable. Adopt multi – plate friction normally closed system. The actuator has high braking torque and safety. The product has the characteristics of small volume, compact structure and high transmission efficiency Has the function of free fly Adopt brand motor, long service life. The mounting bracket can be manufactured separately according to user’s requirement According to the needs of users, the special winch balance valve, shuttle valve. Adopt manual, pneumatic clutch device.
|
5 ton hydraulic winch parameter
|
||||
|
1
|
Output torque (maximum)
|
2266N.M
|
||
|
2
|
Reduction ratio
|
5 i
|
||
|
3
|
Wire rope winding number of layers
|
4
|
||
|
4
|
Wire rope specification
|
φ11
|
||
|
5
|
Output revolution (rated)
|
66Nnom(r/min）
|
||
|
6
|
Brake opening pressure
|
0.8 -1.5Mpa
|
||
|
7
|
Drive motor model
|
BM5 series/optional
|
||
|
8
|
Lubricating oil specification
|
1.5 L grease
|
||
|
9
|
Lifting weight
|
1 T
|
||
|
10
|
Hoisting speed
|
30-40m/min
|
||
Marketing Campaign
Details Images
Product packaging
According to the volume and weight of the product and export requirements, provide multi-layer boxes and iron box packaging.
Transportation is based on customers in different regions using steam, rail, road and air transportation.
Transportation is based on customers in different regions using steam, rail, road and air transportation.
