1ph 3ph 90w low speed ac motor gear reduction permanent magnet synchronous motor
1ph 3ph 90w low speed ac motor gear reduction permanent magnet synchronous motor
Speed control motor is a unit of the controller and motor. It only needs to connect one time. The speed can be easily adjusted by the potentiometer. The controller is fixed with speed- control loop, capacitor, speed enactment and etc.
Parameters of High Torque Low Rpm 5IK90GU AC Induction Motor
The following parameters are for reference only, we can according to customer requirements, please tell me torque ,speed ,noise and life
we can custom parameters and shaft size, please contact us
Motor Type Lead Wire Type |
Output power W |
Voltage V |
Frequency Hz |
Speed Control Range r/min | Rated Torque | Starting Torque mN.m |
Current A |
Capacitor μF |
||
120r/min mN.m |
120r/min mN.m |
|||||||||
Pinion Shaft | Round Shaft | |||||||||
5IK90RGU-AF | 5IK90RA-AF | 90 | 1ph100 | 50 | 90-1400 | 710 | 230 | 405 | 2.75 | 25 |
60 | 90-1700 | 710 | 260 | |||||||
5IK90RGU-EF | 5IK90RA-EF | 90 | 1ph110 | 60 | 90-1700 | 710 | 260 | 410 | 2.6 | 20 |
1ph120 | ||||||||||
5IK90RGU-CF | 5IK90RA-CF | 90 | 1ph220 | 50 | 90-1400 | 710 | 230 | 410 | 1.2 | 5 |
1ph230 | ||||||||||
5IK90RGU-HF | 5IK90RA-HF | 90 | 1ph220 | 60 | 90-1700 | 710 | 260 | 410 | 1.25 | |
1ph230 |
Note:
1. When the motor is approved under various safety standards, the model name on the nameplate is the approved model name.
2. “-A” it means the voltage 110V, the assembly capacitor value it is according the label.
Parallel Shaft Gearhead(Sold Separately)
Gearhead Type | Gearhead Model | Gear Ratio | |
Long Life Low Noise | 5GU K | 3 3.6 5 6 7.5 9 12.5 15 18 25 30 36 50 60 75 90 100 120 150 180 200 | |
5GU10XK(Decimal Gearhead)
|
Dimensions(Unit mm) 90mm AC Speed Control Motor with the Gearbox
Mounting screws are included with gearhead.
It’s the typical specificaitoin for reference only, the AC motor with different voltage, speed, and power to meet your torque and speed requirement. Pls contact us for more product details.
Packing and Delivery Method
1.Outer packing: Standard export carton with required shipping marks
2.Inner packing: Waterproof packing with shock absorbing EPE and cardboard surrounded
3.As per the clients requirements
The Motor can be shipped by UPS/DHL/TNT/EMS/Fedex, by air or by sea. (Pls contact us directly and we will use your preferred ways)
Q: Are you trading company or manufacturer ?
