Introduction
The equipment for purification distillation test rotates and shapes a thin film in negative pressure condition
by heating, evaporates efficiently, and then condenses and recollects solvent to purify and separate.
The rotary evaporator can be made into system devices with Circulating Water Vacuum Pump , Vacuum
Pump , Low Temperature Circulating Pump, Circulating Cooler, Constant Temperature Reaction Bath , Low
Temperature Cooling Liquid Circulating Pump.
Specification
Model |
HEM-01A |
HEM-01B |
Condenser |
Vertical Condenser |
|
Collect Flask |
1L |
|
Rotary Flask |
1L |
2L |
Motor Power |
40W |
|
Power Voltage |
220/110V for Optional |
|
Bath Power |
1200 W |
|
Bath Volume |
2L |
|
Bath Material |
SS304 Combined Bath Material Completely Closed Heated |
|
Evaporation Rate(Water) |
1L/ H |
|
Speed Range |
0 – 120 RPM |
|
Lift and Stroke |
Water Bath Lifting with Manual Control, 150 mm |
|
Glass Material |
GG-17 Glass |
|
Heating Temperature Range |
Rm-99 Degree |
|
Heat Control |
PID |
|
Heat control accuracy |
±1 Degree |
|
Ultimate Vacuum |
0.098 Mpa |
|
Dimensions (W x H x D) |
450×520×650 mm |
|
Weight |
30 kg |
Remark: Heating Temperature Range can be extened to 199 Degree.
Details
Q1: Are you trading company or manufacture?
A:We are professional manufacturer of lab equipment and we have our own factory.
Q2 .Where is your company location ? How can I visit there ?
A :Our factory is in Shenzhen city ,Guangzhou province , China , near Shenzhen International Airport , you can fly to Shenzhen International Airport to visit our factory !
Q3:Could you do design for us?
A:Yes. If you provide us the content and tell us where to put, just tell us how to do in detail.
Q4:Will you provide service beyond the warranty?
A:Yes. Our warranty is two year from the delivery date.
5. What is MOQ ?
A: 1 Set.
