Specification
Functions
|
Slope distance, horizontal distance, vertical height, angle, scanning mode
|
Product Size
|
120mmX72mmX38mm
|
Shell Color
|
Black, white, iron grey
|
Ranging Method
|
Semiconductor laser ranging
(safe for human eyes) |
Laser Wavelength
|
905 nm
|
Ranging Scope
|
3-1500m
|
Ranging Error
|
±0.3m
|
Ranging Resolution
|
0.1m
|
Angle Ranging Scope
|
0-90°
|
Angle Ranging Accuracy
|
0.3°
|
Angle Display Resolution
|
0.1°
|
Ranging Display Mode
|
Transmissive LCD display
in the field of view |
Telescope Magnification
|
8X
|
Telescope Object Diameter
|
28mm
|
Telescope's Field Of View
|
122m/1000m
|
Lens Quality
|
Multilayer coated
|
Working Temperature
|
-20~50℃
|
Operating Humidity
|
≤80%
|
Exit Pupil Diameter
|
3.8mm
|
Exit Pupil Distance
|
12mm
|
Focusing Mode
|
Manual focusing eyepiece
|
Measurement Mode
|
Distance measurement, height measurement, angle measurement, speed measurement, scanning measurement, storage mode, two points
height measurement, golf distance compensation mode |
Protection Class
|
IP54
|
Power Supply
|
CR-2(3V)
|
Tripod Mount
|
Yes
|
Product Description
Certifications
OEM process Introduction
Warehousing Logistics
has an independent warehousing base. It integrates instrument research and development, It supports small batch spot delivery and mass customization.
