fabric laser cutting machine with auto feeder co2 laser cutting machine
Upgrade design
1) Advanced LCD Touch Screen+ USB port+ DSP Offline Control,USB communication.
2) LCD Control System own 128M Big Memory, compatible with AutoCAD, CorelDraw, Photoshop .
3) linear guide rail and optical system, dustproof and lubricate.
4) Special Front and back running-through design, the unique door for the limitless engraved materials through.
5) Professional Honeycomb or Strip work table, which meet the needs of diversified laser procession;
6) Water Cooling System with Alarm Protection function, protect the water circulation from electricity-off.
7) Imported Focus Lens and reflect mirror, Chinese Best Quality Laser Tube, 10000 hours Laser Tube .
9) Red Light Pointer realizes the exact position .
1. Fast curvilinear cutting function: it can cut via any curve fast continuous cutting, the laser heads moving in beautiful arc just evoke your imagination of top grade racing car.
2. To fully support design software, such as CAD, Coreldraw, Photoshop, friendly man-machine interface, live close to the industry needs.
3. Multi-document function: FW series equipment can store as many as 256 working documents, in the case of without the computer, the user can select files in the engraving machine, the mass production of 256 different products.
4. All-optical isolation system with high speed differential input and output circuit design, long distance transmission signal without distortion, strong anti-jamming capability, system has realized the no.12 working state output, state 16-way input, to dock with the user production site easily.
5. Large-format laser cutting incision smooth fine, meet the blanking, machining the whole piece of cloth.
6. Stable light path design, match industrial water-cooled machine, ensure the large-format, cutting the position work surface laser power output is consistent, fast and efficient, stable machining quality.
7. Automatic feeding and discharging, save time, improve work efficiency, it can customize according to customer’s demand level.
8. Feeding system adopts special words with mesa, pedrail automatic feeding device, convenient processing objects move freely on the surface of the cutting machine.
9. The machine used in clothing, textiles, leather and other industries. Mainly used for plate, cloth, leather and other non metal cutting and carving.
|
NO. |
Model |
FW1610/1318/1626/1325/2030 |
|
1 |
Laser medium |
CO2 gas |
|
2 |
Working area |
1600*1000mm/1300*2500mm |
|
3 |
Working table |
B type mesh belt |
|
4 |
Laser power |
80W/100W/130W(optional) |
|
5 |
Power Supply |
220V/50Hz/60Hz |
|
6 |
Min line width |
≤0.15mm |
|
7 |
Positon accuracy |
±0.05mm |
|
8 |
Repetition accuracy |
0.02mm |
|
9 |
Cutting speed |
700mm/s |
|
10 |
Guide rail |
Fast rail from Taiwan |
|
11 |
Transmission method |
Belt Transmission |
|
12 |
Drive system |
Leadshine driving system and stepper motor |
|
13 |
Cooling system |
Water-cooling |
|
14 |
Control system |
Qiancheng |
|
15 |
Control software |
Coreldraw, Photoshop, AutoCAD, etc |
|
16 |
Graphic format support |
PLT, DXF, BMP, JPG ,AI ,ect |
|
17 |
Working environment |
0-45℃, |
|
18 |
Operating Humidity |
5-95% |
|
19 |
Net weight |
250kg According to machine size |
|
20 |
Gross weight |
480kg According to machine size |
fabric laser cutting machine with auto feeder co2 laser cutting machine FW-1325
|
Industrial textile
|
filter cloth, bolting cloth, filter fabric, nonwoven, glass fiber, felt, synthetic fibre, fabric ducting, polypropylene (PP), polyethylene (PE), polyester (PES), polyamide (PA), cement packing, geotextile, coated fabric, PVC fabic, sponge, insulating material and other industrial flexible materials.
|
|
Non-woven fabrics for health & medical
|
insulating material, glass fibre, polyester fibre, Microfiber, Cleanroom Wiper, Glasses cloth, Micro-fiber Wiper, non-dust cloth, clean wiper, paper diaper, etc.
|
|
Home furnishing fabrics
|
upholster, carpet, mat, floor rug, mattress, curtain, doormat, valance, wall paper, tablecloth, bed sheet, bedspread, counterpane, dust cover, sofa fabric, etc
|
|
Garment fabrics
|
sportswear, swimwear, diving suit, exposure suit, liner, lining, adhesive interlining, wadding piece, case-hardened cotton, synthetic leather, genuine leather, etc.
|
|
Automotive interiors
|
car seat cover, car cushion, car mat, car carpet, car rug, pillowcase, air bag, auto dustproof cover, seat belt (safety belt), etc.
|
fabric laser cutting machine with auto feeder co2 laser cutting machine FW-1325
1) Application Industry-Advertisement, arts and crafts, toys, car, mechanism, electron, as well as in trademarks, embroidery, clothing and other industries.
2) Sample
fabric laser cutting machine with auto feeder co2 laser cutting machine FW-1325
