2. The oil cylinder is at the bottom of the load frame, tension space is at the upside of the load frame, compression and bending space is between lower cross head and working table. The lower cross head is driven by motor through decelerator, chain transmission device and screw pair, so realize the adjustment of testing space.
Applications:
used for testing mechanical performance indexes of various metals, nonmetals and composite
materials such as stretching, compression, bending, shearing, peeling, tearing, etc.
The equipment is suitable for manufacturing industries such as metals,adhesives,pipes,profiles,
aerospace,petrochemical industry,waterproof coiled materials,wires and cables,textiles,fibers,
rubber,ceramics,food,medical packaging,textiles,films,wood,paper and other manufacturing
industries as well as product quality supervision departments at all levels.
item
|
value
|
Warranty
|
1yaer
|
Certification
|
CE
|
Customized support
|
OEM, ODM, OBM
|
Place of Origin
|
China
|
Brand Name
|
YUYANG
|
Model Number
|
YYL056
|
Power
|
Electronic
|
Maximum load
|
1Ton
|
Force unit
|
N,KN,Kgf,Lbf
|
Power consumption
|
0.5 kVA
|
Power source
|
220 VAC, 50/60 Hz
|
Volume
|
760x60x210cm
|
Weight
|
200kg
|
Effective width of test
|
380 mm
|
Test stroke (including fixture)
|
800 mm
|
Speed control accuracy
|
±0.2% (0.5 Grade )
|
control mode
|
Computer software sets speed, sets load breaking (breaking), running
time and other control methods
|
||||||
Manual operation box
|
It is convenient to calibrate and position the specimens when loading and
holding them. It can automatically determine the material breaking,
crushing, and stop the machine. It can be set to return
automatically
|
||||||
Curve type
|
Load – displacement, load – time, displacement – time.
Stress – strain, strain – time, stress – time. Curve vertical and horizontal coordinates can be set arbitrarily. |
||||||
Available test data
|
Maximum strength, minimum strength, fracture value, upper and lower
yield strength, tensile strength, compressive strength,
modulus of elasticity, elongation, maximum, minimum, mean value, etc. It has multiple protection such as overload, overcurrent,
overvoltage, undervoltage, overspeed and travel. |
||||||
Load sensing
|
High precision pressure and tension actuator,(multiple sensors can be
installed at the same time – optional)
|
||||||
Test speed range
|
servo-type: 0.5~500 mm/min Speed Promise
|
We are based in Guangdong, China, start from 2018,sell to Southeast Asia(11.00%),Eastern Asia(10.00%),Southern Europe(10.00%),Domestic Market(10.00%),Northern Europe(9.00%),South Asia(9.00%),North America(7.00%),South America(7.00%),Western Europe(7.00%),Eastern Europe(6.00%),Mid East(6.00%),Oceania(5.00%),Central America(3.00%),Africa(0.00%). There are total about 11-50 people in our office.
2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3.what can you buy from us?
Testing Equipment,Tensile Testing Machine,Environmental Test Chamber,Fire Testing Equipment,Induction Heating Machine
4. why should you buy from us not from other suppliers?
We are a high-tech enterprise which is specialized in developing and manufacturing Fire Testing Equipment, Building Material Fire Tester, Wire and Cable Fire Tester, Environmental Test Chamber, Textile Testing Equipment, Toys Testing Equipment and etc.
5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,FAS,CIP,FCA,CPT,DEQ,DDP,DDU,Express Delivery,DAF,DES;
Accepted Payment Currency:USD,EUR,JPY,AUD,HKD,GBP,CNY,CHF;
Accepted Payment Type: T/T,L/C,D/P D/A,Credit Card,PayPal,Western Union,Cash,Escrow;
Language Spoken:English,Chinese
