Product Presentation
How to use ? (After finished piping)
A: press “ON” button on control panel
B: check pressure gauge, when up to 0.6Mpa, open steam valve, and use steam
Safety assurance:
A: pressure: through pressure control, when steam pressure up to set pressure, electric steam generator shut off automatically.
B: with high water level, low level, super high level protectionSafety assurance:
Advantage:
Safer Operation
Electric steam generators are flameless and safer. This eliminates the risk of flareback, firebox explosions, and smoke damage.
Economic
Electrical wiring is less expensive to run than steam piping. Not having a separate electric steam generator room or vented
exhaust saves money.
Use LCD automatic intelligent electronic control system
The use of high-quality core components—316Lstainless steel electric heating pipe
extremely easy to install and use
multiple safety interlock protection
Product parameter
|
Product Type
|
YN27-0.7-D
|
|
Electric power (kw)
|
27
|
|
Rated evaporation (kg/h)
|
38.7
|
|
Source voltage (v)
|
380
|
|
Rated pressure (MPa)
|
0.7/1.0
|
|
Steam temperature (℃）
|
170/185
|
|
Power wire（mm²)
|
10
|
|
Dimension (mm)
|
660*420*1230
|
|
Steam caliber (mm)
|
DN15
|
|
Drain outlet caliber (mm)
|
DN15
|
|
Water inlet caliber (mm)
|
DN15
|
|
Weight (mm)
|
120
|
Product Description
Certificate
Company Introduction
We are specialized in the design, production, sales and service of small and medium-sized boiler setters. We conduct national quality supervision and inspection with a class C boiler manufacturing license. Our company is located in the economic boom area,northwest of China-Shanghai. Our factory covers an area of 12,000square meters, including plant and office building covering an area of 8,600 square meters.
