single phase dc voltage panel meter voltmeter with RS485 modbus 4-20mA analog output AMC72-DV
digital voltmeter with the control equipment to regroup measuring and controlling system.
It can be equipped with RS 485 communication under Modbus-RTU protocol;it has options of analog output,relay alarm and switch state.
| Model | AMC72-DV | ||
| Dimension | |||
| Panel size | 75*75mm | ||
| Cut out | 67*67mm | ||
| Depth | 98mm | ||
| Input | |||
| Input DC voltage range | DC 0~1000V | ||
| Input DC current | 0~10A(Direct input,starting current:5mA) | ||
| 0~9999A(with shunt or hall component | |||
| (current) divider | 75mA | ||
| Hall component | 0~20mA,4~20mA,0~5V,0~10V and so on | ||
| Power consumption | ≤2VA | ||
| Overload | 1.2 times sustainable work, 2times lasts a second | ||
| Accurracy | 0.5 class | ||
| Function | |||
| Phase | Single phase | ||
| Display | LCD | ||
| Analog value |
DC4~20mA,DC 0~20mA(overload<500Ω),DC 1~5v,DC0~5v(overload>1KΩ) and other programmable setting |
||
| Accurracy | 0.5 class | ||
| Option communication | RS485 Communication | ||
| one analog output 4~20mA | |||
| 2DI/2DO | |||
| Alarm(over current) | |||
1. Payment:100% TT in advance
2. Delivery:in 15 working days after payment received.
3. Delivery ways:By sea,air or international courier like Fedex,TNT,DHL and UPS.
