plastic plates and cups making machines milk tea plastic cup making machine

ر.س155,326.91

Clear
Qty:
Compare

Request quotation for: plastic plates and cups making machines milk tea plastic cup making machine

Product Description
Specification
Model
YG-90
Speed
100-120 pcs/min
Cup size
Top Diameter: 60mm(min)-125mm(max)

Bottom Diameter: 45mm(min)-100mm(max)
Height: 60mm(min)-170mm(max)
Raw material
135-450 GRAM
Configuration
ULTRASONIC & HOT AIR SYSTEM
Output
12KW,380V/220V,60HZ/50HZ
Air compressor
0.4 M³/Min 0.5MPA
Net weight
3.4 TONS
Dimension of machine
2500×1800 ×1700 MM
Dimension of cup collector
900 ×900 ×1760 MM
Detailed Images
Highlights of paper cup making machine

Open cylindrical cam

Two cam systems, this design more costly,
but can let the top curling and bottom knurling more accuracy, stable and low noise.
Cam adpots high strength Japan-SKD11 with quenching treatment,resistant to wear.

Gear drive

This system ensure the machine runs with high speed with low noise, smoothly running
and high precision. Instead of chain drive.

Hot air system and protect system

2 set of hot air systems can decrease the rate of leakage. Our
factory using the whole set of Leister(Banko) hot air system with protection system. And our system
sets up on the fixed plate, do not moving during production. Almost impossible to damage.
Also the only one have the protect system that hot parts will go down, keep the distance with paper
cup and cup mould when the machine stop.

Inspection system

Unique design. Our factory set up on final turn station,more stable than
set up on flying tube. Do not need to buy extra inspection machine, less factory space needed.
Inspection accuracy can be set up by self.

Oil lubrication system

Adoptes forced lubrication system to ensure main driving oil supply regularly
and reduce friction and prolong the machine life. The oil circuit adds a clear the oil and filtering system
to clean the oil automaticly. Our factory is the first one to using double layer plate to avoid the scraps
of paper into the machine’s inside.

PLC control system

controlled by simple and efficient PLC system
