oil filter element,epe hydraulic oil filter element

 oil filter element

Filter performance: filtering accuracy: 1 to 100 μm working pressure (MAX): 21MPa Working medium: the general hydraulic oil, phosphate ester hydraulic oil, emulsion, water – glycol Operating Temperature: -30 °C to +110 ° C
(B), lubricating oil filter
1, to allow the system to quickly reach and maintain the desired level of oil clean.
2, the oil life can be extended.
Reduce bearing wear.
(C), the high-pressure oil filter
1. Products summarized
This series of high-pressure oil filter is installed in the oil passage of the hydraulic system used to remove the worn metal powder of each element of the hydraulic system and other mechanical impurities in the oil passage to keep clean, and to extend the life of the hydraulic system. The low pressure also has a series filter bypass valve, when the filter is not timely replacement, bypass valve will open automatically, to ensure the normal operation of the system. This series is a substitute of similar products in the United States, Germany, Britain, Italy and other countries.
2 high-pressure oil filter uses
The series filter cartridge is installed in the oil passage of the hydraulic system is used to remove the worn metal powder of each element of the hydraulic system and other mechanical impurities in the oil passage to keep clean, and to extend the life of the hydraulic system.
The low pressure also has a series filter bypass valve, when the filter is not timely replacement, bypass valve will open automatically, to ensure the normal operation of the system.
This series is a substitute of similar products in the United States, Germany, Britain, Italy and other countries.
Technical conditions of high pressure oil filter
1 filter Withstand: 21MPa
Operating temperature: -10 to +100 °C
Filtration accuracy: 5 ~ 20μm
4. Working medium: hydraulic oil.
