Product Description
Water well drilling rig
Family use small foldable drilling rig; small water well drilling rig for sale
Product Introduction
This machine is mainly used for geothermal drilling, farm irrigation, house yard, gardens and water well drilling, drilling diameter is 70-300mm, and drilling depth is 60-80m. It also can be used in small building piling, like farmhouse or factory and so on.
Features:
1. Light weight. The main engine is only about 0.135tons.
2. Unique design and simple drilling structure.
3. Easy to transport and operate.
4. Can drill through hard stratum, unless thick rock layer.
5. Can drill up to 80m depth. Equipped with hoist, reduce the labor intensity.
6. High efficiency, the drilling speed can reach 20meters depth per hour in plain area.
7. Assure easily operation and long life span to save more labors and money for you.
8.Packed in wood box, the CBM is about 2.0m³, the total weight (complete set) is about 850kg.
Product Introduction
This machine is mainly used for geothermal drilling, farm irrigation, house yard, gardens and water well drilling, drilling diameter is 70-300mm, and drilling depth is 60-80m. It also can be used in small building piling, like farmhouse or factory and so on.
Features:
1. Light weight. The main engine is only about 0.135tons.
2. Unique design and simple drilling structure.
3. Easy to transport and operate.
4. Can drill through hard stratum, unless thick rock layer.
5. Can drill up to 80m depth. Equipped with hoist, reduce the labor intensity.
6. High efficiency, the drilling speed can reach 20meters depth per hour in plain area.
7. Assure easily operation and long life span to save more labors and money for you.
8.Packed in wood box, the CBM is about 2.0m³, the total weight (complete set) is about 850kg.
|
Type
|
HC-80
|
Max. Drilling Diameter
|
70-300mm
|
|
Max. Drilling Depth
|
60-80m
|
Total Power
|
8.8 kw
|
|
Engine Power
|
1.2kw
|
Lifting Power
|
1.0kw
|
|
Pump
|
2.2kw,220V
|
Capacity of hoist
|
1.0t
|
|
Height of tower
|
3m
|
Total Weight
|
450kg
|
