Liquid mode : Test density, concentration% (only takes 50ml of sample, one-click direct reading liquid)
2.Fast direct reading type, reading within 0.1 seconds, fully automatic zero tracking, full tare weight
3.Optional charging function, power off can also be used, single life time is about 48 hours
4.Has the function of upper and lower limit setting, automatic alarm for data failure
5.With actual water temperature compensation function, adapt to the change of temperature difference between north and south/early and late
6.Set the media density, use water as the medium, or use other liquid media
7.Repeat measurement error range ≤±0.001g/cm3
8.RS RS-232C communication interface for easy connection between PC and printer, optional MZ-P1 printer for printing measurement data
Solid mode measurement procedure
2,Place the sample into water basket, press the MEMORY button. Display Density and volume directly.
(If the test sample is alloy, pressMENU button to display alloy mixing ratio)
Liquid mode measurement procedure
2. Put the standard block into the liquid, one-click direct reading density (specific gravity), concentration%
|
Model
|
MZ-S300
|
MZ-S600
|
MZ-S150
|
MZ-S1200
|
|||
|
Maximum weighing
|
300g
|
600g
|
150g
|
1200g
|
|||
|
Density accuracy
|
0.001 g/cm3
|
0.001 g/cm3
|
0.0001 g/cm3
|
0.001 g/cm3
|
|||
|
Repeatability
|
±0.001g/cm3
|
±0.001g/cm3
|
±0.0002g/cm3
|
±0.001g/cm3
|
|||
|
Concentration accuracy
|
±0.1% (repetitive)
|
||||||
|
Density range
|
0.001~99.999g/cm3
|
||||||
|
Measurement type
|
Solid mode: arbitrarily shaped block solids, granules
Liquid mode: Any fluidity can be measured |
||||||
|
Measuring principle
|
The principle of the Archimedes replacement method, the test time is about 5 seconds.
|
||||||
|
Display parameters
|
Solid mode: density, volume, alloy content mixing ratio %
Liquid mode: density (Specific gravity), concentration
|
||||||
|
Parameter setting
|
Water temperature setting, medium liquid density setting
|
||||||
|
Correction method
|
One-button automatic correction
|
||||||
|
Output method
|
RS-232C standard communication interface, convenient test data output and printing
|
||||||
|
Power supply
|
AC~220V / 50HZ(The export power supply needs to be customized, and it can be noted before ordering.)
|
||||||
|
Standard accessories
|
1. host 1pc
2. sinks 1 pc 3. measuring benches 1 pc 4. rafters 1 pc 5. rows of bubble droppers 1 pc 6. weight 1 pc 7. power transformers 1 pc 8. measuring granules 1 set 9. measuring floats 1 set 10. liquid special density components 1 set |
||||||
|
Optional accessories
|
Thermal printer
Quartz standard block (for general liquid measurement, standard set) Teflon standard block (corrosive liquid measurement needs to be selected) Stainless steel standard block (optional for high viscosity liquid measurement) |
||||||
When you receive a product from Qun Long, it must be debuged by our production staffs,technical staff and warehouse management. And our technical staffs have more than 10 years experience. We can guarantee the warranty for three years from the date of receipt. If our machine fails to perform properly because of defects in materials or workmanship during three years warranty, We will be responsible for fixing or replacing new machine .
2.How about after-sales Service
(1)If errors occur, please refer to the troubleshooting tips of the instruction manual
(2)Please contact with our after-sales service department or distribution in time if can’t clear fault
(3)When you contact us with a service problem, we will act within 12 hours and provide solution within 24 hours.
(4)After-sales line : 0755-82596242
(5)If the product have some big troubles and it must be sent back to our factory to repair during its warranty period, you just need to shipping the product to us and we will sent you a new one.The service is excluding if the machine is breakdown caused by following reasons:
a:Wrong operation
b:Fixed or refitted personally
c:The machine itself is not the reason caused breakdown
d:Applying the machine under the serious condition. Such as high temperature, moist, corrosive gas, or vibration.
e:Move or transportation as soon as installed
f:Consumables and easy-loss components
g:Natural disaster
3.How many days can you receive the products?
Product in stock will be sent within 48 hours. Delivery time is about 5-7 days.
4.How to shipping the product?
Product will be sent by International Express by air. Such as DHL, UPS, FEDEX, TNT, SF.
5.What is our return policy?
You are allowed to return goods within 7 days from the date of receipt. To return products,please contact our customer service with your invoice number, the item to be returned and the reason for the return. Goods must be returned freight prepaid. Returns will be subject to a restocking charge. Products can not be returned back when the products have been used or modified.
6.Are we manufacturer made copy product or original product?
We are the original manufacturer for densimerter, Mayzun is our own brand. The model starts with MZ is belongs to us generally.
Qun Long (MAYZUN is our brand) have been specialized in density field since 2009. Qun Long as a professional density meter supplier , has maintained a constant belief：First – class quality , professional technology team and services team，ample supply and prompt delivery.
