max.head 52m high corrosion and wear resistance bare shaft centrifugal slurry pumps

ر.س19,731.69

Clear
Qty:
Compare

Request quotation for: max.head 52m high corrosion and wear resistance bare shaft centrifugal slurry pumps

— Products Description —

MAH slurry pump
The MAH series Mineral Processing Heavy Duty Centrifugal Slurry Pump is designed for the continuous pumping of highly abrasive, high density slurries with minimal maintenance requirements. The MAH series slurry pump will maintain high efficiencies over the wear life of its components.
— Details Images —
— Product Parameters —
Type
Max. power
Capacity
Head
Speed
Max.Eff
NPSH
Impeller Dia.
Max.particle size
(kw)
(m³/h)
(m)
(r/min)
(%)
(m)
(mm)
(mm)
MAH1.5-1
15
12-28
6-65
1200-3800
40
2-4
150
14
MAH2-1.5
15
32-72
6-58
1200-3200
45
3.5-8
185
19
MAH3-2
30
39-86
12-64
1300-2700
55
4-6
215
25
MAH4-3
60
86-198
9-52
1000-2200
71
4-5
245
28
MAH6-4
120
162-360
12-56
800-1500
68
5-8
365
44
MAH8-6
120
360-830
10-61
500-1140
72
2-9
510
63
MAH10-8
260
612-1368
11-61
400-850
71
4-10
685
76
MAH12-10
560
936-1980
7-68
400-750
82
1-5
760
86
MAH14-12
560
1260-2772
13-63
300-600
77
3-10
965
90
Rubber Pumps Material
Metal Pumps Material
No
Part
Material
No
Part
Material
1
Base
Cast Iron
1
Base
Cast Iron
2
Shaft
4140 High Tensile Steel*
2
Shaft
4140 High Tensile Steel*
3
Bearing Assembly
Timken (Cast Iron Body)
3
Bearing Assembly
Timken (Cast Iron Body)
4
Shaft Sleeve
420 Stainless Steel
4
Shaft Sleeve
420 Stainless Steel
5
Pump Casing
Cast Iron
5
Pump Casing
Cast Iron
6
Frame Plate Liner Insert
Rubber
6
Frame Plate Liner
27% Chrome White Iron
7
Cover Plate Liner
Rubber
7
Volute Liner
27% Chrome White Iron
8
Impeller
Rubber Coated High Tensile Steel
8
Impeller
27% Chrome White Iron
9
Throat Bush
Rubber
9
Throat Bush
27% Chrome White Iron
10
Cover Plate
Cast Iron
10
Joint Rings
Rubber
11
Stuffing Box
Cast Iron
11
Cover Plate
Cast Iron
12
Expeller
27% Chrome White Iron
12
Stuffing Box
Cast Iron
13
Expeller Ring
Natural Rubber
13
Expeller
27% Chrome White Iron
14
Bolts
Zinc Plated Steel
14
Expeller Ring
Natural Rubber
15
O-rings
Nitrile Rubber
15
Bolts
Zinc Plated Steel
16
Seals
Rubber
16
O-rings
Nitrile Rubber
17
Seals
Rubber
17
Seals
Rubber
— Recommend Products —

Submersible Slurry Sump

Diesel Engine Fire Pump

Submersible Sand Pump
— Company Profile —
Modo Pump Co.,Ltd. is one over 30 years experienced pump manufacturer (established at 1986) in mining and mineral, power plant, dredging and dredge, hydraulic, irrigation, pulp transfer, chemical, construction, sea water and oil & gas transfer etc.; Modo Pump Co.,Ltd. is the pump factory has its own pump selection & design, research and development team to assure provide you efficient, energy saving slurry pump, water pump, diesel water pump, chemical pump and irrigation pump in selection & design, use and maintenance program.

Our products include slurry pump, sewage pump, water pump, acid resistant or chemical pump, irrigation pumps, fire pumps and other products exported to over 90 countries all over the world. The application covers many fields, such as mining and mineral processing, dredger, tailings transportation, mining, steel, desulfurization pump, boiler feed water, construction, irrigation, water conservancy facilities, sewage treatment, drainage and water supply.

— Application —
— Why Choose Us —
— FAQ —
1, What information is needed to offer a slurry pump?
The pump model or the below information:
Liquid:___
Capacity:___ m3/hr
Head: ___ m
PH:___
Specific of gravity:___
Voltage:___V, Frequency:___hz

2, What material pump can you supply?
A05, Natural rubber, ceramics, polyurethane etc.

3, Can you supply special or OEM parts?
Yes, please send me the detailed drawing or parts code to check.

4, Do you only supply pumps? Could you supply driven equipment?
Yes, sure ,the pumps could be coupled with motor and diesel engine, below brands for your reference:
Motor: WEG, SIMENS ,ABB, TECO ,and Chinese brands
Diesel engine: Cummins, Deutz, Perkins,Volvo,MITSUBISHI, Caterpiller,MTU,and Chinese brands.

5, What is the delivery time?
10days for normal pumps.


Type

slurry pump, Trash Pumps, Centrifugal Pumps, Dewatering Pumps

Maximum Head

52 m

Maximum Flow Rate

180 m3/hr
