Product Description
Forklift is a generic transportation vehicle, used for loading and unloading, short distance transport, heavy lifting, usually using diesel or battery driven. Simple operation and fast driving.
Widely used in railway station, port, airport, factory, warehouse, etc, is efficient equipment mechanical for loading andunloading, stacking and short distance transport.
| Model | 30 | 35 |
| Rated load lifting capacity | 3000kg | 3500kg |
| Center distance of rated load | 500mm | 500mm |
| Door frame inclination (front/back) | 6/12° | 6/12° |
| Max. running speed (full load/no load) | 20km/h | 20km/h |
| Max. climb (full load) | 20% | 20% |
| Minimum outside turning radius | 2510mm | 2510mm |
| Max. braking distance | 2.5m | 2.5m |
| Lifting speed | 450mm/s | 300mm/s |
| Overall dimension length (up to the fork back) | 3757mm | 3757mm |
| The width of the shape | 1226mm | 1226mm |
| Overall height (up to roof guard) | 2125mm | 2125mm |
| Dead weight load | 4220kg | 4220kg |
| Engine | 4D27G31 | 4D27G31 |
| Model | SCD-30 | ||
| Rated load lifting capacity | 3000 KG | Min. ground clearance | 125 mm |
| Center distance of rated load | 500 mm | Max. braking distance | 2.5 m |
| Standard mounting height | 3000 mm | Overall dimension length | 2502 mm |
| Free lifting height | 145 mm | The width of the shape | 1265 mm |
| Door frame inclination (front/back) | 5/10º | Overall height | 2110 mm |
| Max. running speed (full load/no load) | 14/14 Km/h | Battery standard | 80/500 V/Ah |
| Max. Lifting speed (full load/no load) | 250/400 mm/s | Drive motor | 10.2DC KW |
| Max. climb (full load) | 13/14 % | Front tire | 23×9-10 |
| Minimum outside turning radius | 2230 mm | Rear tire | 18×7-8 |
