Lab use electric resistance furnace bronze melting induction furnace
Product solution
We offer various series of standardized products to satisfy the requirements of most customers. We can also provide solutions tailored to your unique requirements on heat treatment. We are ready to serve you upon request.
Application
The products are widely applied in the chemical analysis and physical determination for labs in industrial and mining enterprises, scientific research institutes, etc; sintering stoneware, porcelain and ceramics ;high-temperature heat treatment for metal annealing quenching and tempering
Technical Data
|
Model |
NB2-2.5-10G NB2-2.5-10T |
NB2-4-10G NB2-4-10T |
NB2-8-10G NB2-8-10T |
NB2-10-10G |
NB2-12-10G |
NB2-18-10G |
|
Hearth dimensions(mm) |
200X120X80 |
300X200X120 |
400X250X160 |
300X200X300 |
500X300X200 |
500X500X800 |
|
Furnace volume |
2L |
7.2L |
16L |
18L |
30L |
200L |
|
Design temperature |
1000°C |
|||||
|
Highest temperature |
950°C |
|||||
|
Temperature control precision |
±1°C |
|||||
|
Temperature control method |
PID temperature controller |
|||||
|
Temperature rise rate |
≤15°C/min for G-series,≤50°C/min for T-series |
|||||
|
Input power |
2.5kw |
4kw |
8kw |
10kw |
12kw |
18kw |
|
Source voltage |
AC220V |
AC220V |
AC380V |
AC380V |
AC380V |
AC380V |
|
Heating elements |
Fe-Cr alloy heating wire(0Cr25AL5) |
|||||
|
Sensor |
K-type |
|||||
|
Dimensions(mm) |
480X400X570 |
590X520X620 |
730X570X720 |
550X770X550 |
770X880X560 |
900X1100X1200 |
Please kindly tell us following informations before you order:
1.The Max temperature you need
2.The Max furnace inner size
3.The material of hearth:G or T series
a.T-series hearth
It adopts high-density ceramic fiber, an emerging modern refractory material, featuring light weight, rapid temperature rise, time saving, etc, to satisfy the requirements on rapid sintering under various conditions. It is the optimal substitute for traditional hearth.
b.G-series hearth
It adopts traditional refractory material and features wide application, high performance-price ratio, long service life etc.
Machine pictures
Details pictures
Packing pictures
1.Company Show
2.Factory Show
1.Certification
2.Warranty and After-Sale Service
♥♥We Supply 1 Year Warranty , And Lifelong Free Technical Guiding And Training.♥♥
