HOT SALE bicycle handle pipe bending machine best tube bender FOR
Product Detail
| Model | YGWG51 |
| Maximum bending capacity | ≤51mm |
| thickness | 2-3.5mm |
| Bending speed | 4-8r/min |
| quality of bending angles | 9 |
| Bending maximum angle | 200° |
| Bending minimum angle | 30 |
| Motor Power | 3kw-4 poles |
| Voltage | 380v;50Hz |
| Weight | 260kg |
Steel Pipe bending machine
Product Description
Range of application: Yugong CNC(Computerized Numerical Control) platform bending electric automatic pipe bending machine – Furniture manufacturing, fitness equipment, gate processing, chemical pipelines and other sectors of the large quantities of pipe processing production, mainly for steel pipe, pipe, square tube, flat tube bending arc work.
Features of the steel pipe bending machine
mechanical transmission part: the use of Turbo reducer which is our self-made/independent research results – durable, strong, bending process wheel mold rotation, with high-intensity one-time shape of the pressure pipe bending. We will give you the biggest discount! Quickly call to order it! . on the sale and dealers: We will provide a complete after-sales service
2: part of the circuit control: the use of advanced embedded microcomputer intelligent control system control, angle input to digital, get started simple.
3: Product advantages:
by the experienced professional and technical personnel production, stable performance;
intelligent chip control, fast response, high sensitivity, intelligent control system can be set. Urgent need to use
Encoder control angle, strong signal sensing, accurate running angle, high repeat precision, and small error.
from the root to solve the “mechanical” control can not accurately stop the angular deviation caused by large problems. CNC bending machine electric automatic pipe bending machine
Working principle
Parameter
|
Model |
YGWG51 |
YGWG76 |
|
|
Maximum bending capacity |
≤Φ51 |
Φ76x5mm |
|
|
thickness |
2-3.5mm |
3-5mm |
|
|
Bending speed |
4-8r/min |
3-5r/min |
|
|
quality of bending angles |
9 |
|
|
|
Bending maximum angle |
200° |
190° |
|
|
Bending minimum angle |
30 |
|
|
|
Motor Power |
3kw-4 poles |
5.5kw |
|
|
Voltage |
380v;50Hz |
380v |
|
|
Foot switch voltage |
5v
|
|
|
|
Dimension |
930*680*850mm |
1150x700x1000mm |
|
|
Weight |
260kg |
420kg |
|
Optional Payment Terms
1) T/T 30% deposit in advance, T/T 70% before shipment.
2) L/C at sight ( high cost, not very advise).
3) Escrow.
We accept TT, L/C ,Western Union, etc. according to which one is convenient for you!
Packing & Shipping
within 3-7days after receiving the payment(modified need more )
We normally use Container or wooden boxes which depends on the goods.
The goods can be disassembled, will be shipping by Container.
The goods can not be disassembled, will be shipping by Bulk Cargo or Flat Rack.
After-sales Service
1) Warranty time is 12 months from the date of commission, or 18 months from the factory delivery, the first shall prevail.
2) Special Operation and maintenance video guide for the Customers.
3) Technical person work-site commission service support.We can send engineers to support you to install large sprayer machine.
4) Help you do worker training
5) On-line support 24 hours.
PACKAGE:
Standard export carton packing.
DELIVERY TIME:
3-20 days after confirming order,detail delivery date should be decided according to
production season and order quantity.
1. Packaging: 1)Wrapped by protective film;
2)Packed by standard import & export wooden cases or carton boxes.
2. Shipping: By logistics; by automobile; by train; by shipping; by air etc.
About Us
Henan Yugong Machinery Co., Ltd. is a large machinery manufacturing enterprise which focuses on research and development, production and sales of mining, tunnel construction, road and bridge construction equipments and so on.
We believes that good quality can give us survival, thus we only provide you top products. All the products with high quality meet international standards and are highly estimated by all clients at home and abroad.
All the staff in our company are professionally trained, so we can recommend you the most appropriate equipment. Every machine will be strictly examined before delivery.
Any question about the machine will be replied within 24 hours. Welcome you to be our new client!
