Auto/Manual range.
ACV and ACV measurements reach up to 1000V.
DC measurement accuracy reaches up to 0.03%.
0.1ohm resistance and 1µV voltage resolution.
Voltage/Current linear frequency measurement.
Logic frequency/duty cycle measurement.
Capacitance measurement from 0.01nF to 5000µF.
AC/AC + DC true RMS/dBm measurement.
MAX/MIN/MAX-MIN value, relative value, average value measurement.
Data hold.
RS-232C interface and PC Windows software.
Software calibrates automatically.
Full overload protection.
Color fluorescent double display.
Full screen memory function
|
Specification |
Range |
Accuracy |
|
DC Voltage |
50 mV |
±(0.03%+10) |
|
500 mV/5 V/50 V/500 V/1000 V |
±(0.03%+6) |
|
|
AC Voltage |
50 mV//500 mV/5 V/50 V/500 V/1000 V |
±(0.5%+40) |
|
DC Current |
500 µA |
±(0.15%+15) |
|
5 mA/50 mA/500 mA |
±(0.15%+10) |
|
|
5A/ 10A |
±(0.5%+10) |
|
|
AC Current |
500 µA/5 mA/50 mA/500 mA/5A(40Hz~1kHz) |
±(0.75%+20) |
|
500 µA/5 mA/50 mA/500 mA/5A(1kHz~10kHz) |
±(1.0%+20) |
|
|
500 µA/5 mA/50 mA/500 mA/5A(10kHz~20kHz) |
±(2.0%+20) |
|
|
10A(40Hz~1kHz) |
±(1.0%+20) |
|
|
10A(1kHz~10kHz) |
±(5.0%+20) |
|
|
Resistance |
500Ω |
±(0.1%+10) |
|
5kΩ/ 50 KΩ/500 KΩ |
±(0.1%+5) |
|
|
5MΩ |
±(0.1%+10) |
|
|
50MΩ |
±(0.5%+10) |
|
|
Capacitance |
50 nF/500 nF/5 µF/50 µF |
±(1.0%+15) |
|
500 µF/5000 µF |
±(2.0%+10) |
|
|
Logic Freqneucy |
5 Hz ~ 2 MHz |
±(0.006%+4) |
|
Duty Cycle |
10% ~ 90% |
±10% |
|
Linear Freqneucy |
500mV/5V/50V/500V/1000V/5000µA/500mA/10A |
±(0.006%+4) |
PACKAGE:
For small items, we will fully pack with Yellow Tape to protech water.For standard carton we will pack with stretch film and client’s shipping mark mentioning company name,carton number.
DELIVERY TIME:
We have all items in stock, for sample we can send out within 3 working days, for OEM we can send within 35 working days,mosty depends on the quantity and our sales season!
