3D CNC 1325 Router Cylinder Boring And Milling Machine With Rotary with rotary for furniture making made in china

This product is currently out of stock and unavailable.

Compare

Request quotation for: 3D CNC 1325 Router Cylinder Boring And Milling Machine With Rotary with rotary for furniture making made in china

3D CNC 1325 Router Cylinder Boring And Milling Machine With Rotary with rotary for furniture making made in china

Best price ARTECH 4 axis 1325 atc wood cnc router engraving machine with rotary for furniture making made in china

Description

Feature of wood cnc router:

1. Ball screw for Z axis.It’s stable running,precision and fast.

2. X,Y axis are gear rack,steady rate transmission,fast speed and high efficiency.

3. With Syntec control system,easy to learn operate and high precision.

4. This atc wood cnc router designed with risk type auto tool changer.Differents tool can be installed in tool holder.Spindle working one by one,more convenient to change the tool,high efficiency and save time.

5. Heavy duty frame and gantry,very strong and stability.

6.This cnc router is installed the rotary at side of the machine body.So that no need to remove the rotary whenever you work on flat bed or rotary.You just need to move the spindle over flat bed or rotary each by the controller.It is easier to move it and save must time.

Click here

Get more other cnc machine information

 Technical Parameter of wood cnc router:

ITEM

1325 CNC ROUTER

OPTIONAL PARTS

X Y Z Working area

1300*2500*200mm

Other size is optional

Table size

1460*3040mm



X,Y,Z Traveling Positioning Accuracy

±0.01/300mm



X,Y,Z Repositioning Accuracy

±0.01 mm



Table Surface

T.slot table, hold the material by clamps

 vacuum table

Machine body

Thick,strong and high quality steel tube welded



X,Y axis driving way

Rack and Pinion /Linear square guide rails&

Blocks imported from Taiwan, HIWIN brand



Z axis driving way

Ball screw / Linear square guide rail and blocks

imported from Taiwan, HIWIN brand



Max. Power Consumption

2.0kw(without spindle)



Max. Rapid Travel Rate

33,000mm/min



Max. Working Speed

25,000mm/min



Spindle Power

12kw Italy air cooling spindle

Chinese

water cooling spindle

Spindle Speed

0-18000 RPM

0-24000RPM

Inverter

Fuling

Yaskawa, Panasonic,Delta

 or others

Working Voltage

AC380V/50-60Hz/3PH

AC220V/50-60Hz/Single or 3 phase

Command Language

G Code



Control system

Syntec

DSP,Mach 3, NC studio

 or others

Computer Interface

PCI

USB/PCI

X,Y Resolution

< 0.01mm



Software Compatibility

Type3/  Artcam Software)



Dust collector

2.2KW with 2 bags

3KW/4KW

Running Environment

Temperature

0°-45°



Relative Humidity

30%-75%



Packing Size

2030*3100*1740mm



Net weight

1000kg



Gross weight

1100kg




Click here

get more other cnc machine information

Application

Application of wood cnc router:

1. Woodworking industry:wood crafts,picture frames cutting,handicraft carving wave plates,wooden door production and processing.

2. Advertising industry:advertising materials such as PVC,acrylic,double color plate.

3. Stone working industry:such as natural marble,granite,artificial stone,tombstones,milepost,ceramic tile,glass and other materials.

4. Metal industry:carving aluminum,copper,stainless steel and so on.

Best price ARTECH 4 axis 1325 atc wood cnc router engraving machine with rotary for furniture making made in china

Production Process:

Best price ARTECH 4 axis 1325 atc wood cnc router engraving machine with rotary for furniture making made in china

Package and Delivery

Package and Delivery of wood cnc router:

Package Detail: 1.Outside package:Standard plywood package.

                           2.Inner package:Stretchy film and plastic film for humidity.

                           And we can package according to your requests.

Delivery Detail:  For atandard machines,it will be 7-15 working days after payment;For non-standard machines and customized machines according to clients’ specific requirements,it will be 15 to 30 working days after payment.

Best price ARTECH 4 axis 1325 atc wood cnc router engraving machine with rotary for furniture making made in china

After Sale Service

After Sale Service of wood cnc router:

1. Engineers availbal to service machinery overseas.

2. 1 year guarantee for whole machine.

3. Technical support by phone,e-mail,whatsapp and skype.If you have any problems,we will within 12 hours to solve it.

4. You will be get free training advice towards our machine in our factory.

5. If you need any component of the machine,we will provide the best price for you.

6. Friendly English version manual and operation video CD disk.

Company Information

Artech is comprehensive in the production, design, manufacturing, trade and service of CNC machine, and provide high quality and good efficient CNC machines worldwide. With a strong staff team, “Brand ArtechCNC” gained success in woodworking engraving machine, advertising engraving machine, stone engraving machine, metal engraving machine, laser engraving machine and laser cutting industry equipment. The production facilities occupies China’s forefront in development and expansion.

Best price ARTECH 4 axis 1325 atc wood cnc router engraving machine with rotary for furniture making made in china

Best price ARTECH 4 axis 1325 atc wood cnc router engraving machine with rotary for furniture making made in china

FAQ

Q1 For offer the most suitable machine,how should i do ?

1).The exact material you want to engrave/cut? (such as wood, acrylic, cloth, fabric, leather, metal…. ? )

2). For the Spindle Power, may I know the cutting or engraving depth you want?

3). The working area you demand? (such as max dimension of material, width*length,1200*1200mm,1300*2500mm,2000*3000mm, etc…

4). Do you want to engrave on planar &flat surface or round &curved surface?

If yes,the machine shall be added optional items, such as rotary attachment. if you can provide some pictures of your products,that would be great! after your tell us these,we will send you more information about the machine and price.



Q2.If we donot know how to use the machine,can you teach us?Yes,we will ,if you come to China,we will offer you free training until you can use machine freely.And if  you are busy ,we will have the special engineer to your country,but you need to bear some fee, like tickets and hotel and meal.



Q3.How about your after-sales service?

we offer you 24 hours service phone,skype or MSN.



Q4.How about your guarantee period?

one year and during the time,if you have  any questions ,we will solve it for free.
