3-6 ton heavy duty towable backhoe mini backhoe loader for sale

ر.س48,258.74ر.س68,836.84

Clear
Qty:
Compare

Request quotation for: 3-6 ton heavy duty towable backhoe mini backhoe loader for sale

3-6 ton heavy duty towable backhoe mini backhoe loader for sale_02.jpg

Product Description


You know what difference about our backhoe loaders?

-Our backhoe loaders deliver the power and precise handling you need when operating in areas     where using larger equipment is not practical. Because of their relatively small frame size and   versatility our backhoe loaders improve construction productivity and lower your machine     operating costs.

-Our backhoe loaders were designed as a system, which means every part plays a critical role.

 It’s why we’ve made it easier to maintain your machine.

-The shape of our buckets improves digging, loading and material retention.

Product Parameters

Model

VTZ10-20

VTZ15-26

VTZ15-28

VTZ25-30

Dimensions (mm)

5500*1720*2650

5800*1850*2750

6200*1960*2850

6800*2040*2850

Operating Weight

3400 kg

4800 kg

5400 kg

6000 kg

Rated Load

1500 kg

2000 kg

2500 kg

3000 kg

Rated Power

40 kw (55 hp)

55 kw (75 hp)

76 kw (104 hp)

92 kw (125 hp)

Engine Type

Diesel, 4-Cylinder, 4-Stroke, In-line, Water Cooling

Backhoe Capacity

0.1 m³

0.15 m³

0.2 m³

0.3 m³

Loader Capacity

0.75 m³

1.0 m³

1.25 m³

1.5 m³

Backhoe Max. Digging Depth

2000 mm

2700 mm

2600 mm

2600 mm

Backhoe Max. Digging Height

3300 mm

4200 mm

4300 mm

4400 mm

Backhoe Max. Digging Radius

2900 mm

4600 mm

4600 mm

4600 mm

Backhoe Max. Dumping Height

1850 mm

2200 mm

2300 mm

2300 mm

Loader Max. Dumping Height

2800 mm

3300 mm

3500 mm

3500 mm

Loader Max. Dumping Distance

800 mm

900 mm

900 mm

900 mm

Backhoe Max. Breakout Force

25 kn (2550 kg)

28 kn (2856 kg)

28 kn (2856 kg)

28 kn (2856 kg)

Loader Max. Breakout Force

36 kn (3672 kg)

36 kn (3672 kg)

42 kn (4284 kg)

42 kn (4284 kg)

Travel Speed

0 – 26 km/h

0 – 26 km/h

0 – 30km/h

0 – 30 km/h

Gradeability

30°

30°

30°

30°

Min. Turning Radius

3500 mm

4000 mm

4500 mm

4500 mm

Working Pressure

16 MPa

16 MPa

16 MPa

16 MPa

Wheel Tread

1630 mm

1550 mm

1630 mm

1630 mm

Wheel Base

2670 mm

2150 mm

2670 mm

2670 mm

Tire Model

20.5 – 16

23.5 – 16

16/70 – 20

16/70 – 20

Tire Pressure

250 KPa

250 KPa

250 KPa

250 KPa

Transmission Type

Hydraulic

Hydraulic

Hydraulic

Hydraulic

Braking System

Air Assist

Air Assist

Air Assist

Air Assist




Attachments options make our backhoe loaders multifunctional:

Invest in what you already own – give your machine attachments and equip it to do more. And because our attachments are engineered, balanced and tested to each model, they promise to minimize stress and optimize performance.

Product Details


Customer Feedback

Many applications – maybe you know, but more than you know:

Our backhoe loaders provide superior digging, trenching, back-filling and material handling capability and can be used for many applications, including but not limited to:

– General Construction.

– Demolitions and Excavations.

– Landscaping.

– Breaking Asphalt and Paving.


Company Information


Contact Us


Model Number

VTZ25-30, VTZ15-28, VTZ10-20, VTZ15-26

Rated Load

1500 KG, 2000 KG, 2500 KG, 3000 KG
