2KG Silver Gold Iron Brass Mini Brass Melting Furnace — Economic Price with High Quality
Furnace / Melting Furnace / Brass Melting Furnace
Features:
The machine adopts medium frequency induction heating, DSP digital control circuits, the actual heating temperature can reach 1600 ℃ (2900 ℉)
Used for refining precious metals (gold, silver, copper, iron, etc.).Using the patented magnetic heat technology driving technology, the operation is simple, the melting speed is fast,low energy consumption, the machine volume is small, the outside part is low heat storage.It is a new high performance portable gold melting furnace.
Features:
The machine adopts medium frequency induction heating, DSP digital control circuits, the actual heating temperature can reach 1600 ℃ (2900 ℉)
Used for refining precious metals (gold, silver, copper, iron, etc.).Using the patented magnetic heat technology driving technology, the operation is simple, the melting speed is fast,low energy consumption, the machine volume is small, the outside part is low heat storage.It is a new high performance portable gold melting furnace.
|
Technical Parameters of 2KG Silver Gold Iron Brass Mini Brass Melting Furnace — Economic Price with High Quality
|
||||||
|
Product Name
|
2KG Silver Gold Iron Brass Mini Brass Melting Furnace — Economic Price with High Quality
|
|||||
|
Keywords
|
Furnace/ Melting Furnace / Brass Melting Furnace
|
|||||
|
Voltage
|
200V – 235V (Furnace)
|
|||||
|
Working Frequency
|
50HZ - 60HZ (Melting Furnace)
|
|||||
|
Power input:
|
2KG 5000W Support 100%full load (Brass Melting Furnace)
|
|||||
|
System protection:
|
Double IGBT Over heat protection,Lack water protection.
Non – pot circuit detection function. Automatic many kinds of internal fault detection procedures, such as driving frequency error automatic alarm protection, such as a variety of protection circuits. |
|||||
|
Water Cooling system:
|
External water cooler, or direct tap water, only a minute 1L of water flow can be used normally.
|
|||||
|
Melting Temp:
|
The actual temperature can be heated up to more than 1600 ℃, the temperature can be raised rapidly, the electricity can be saved, the smelting cost is low, the cost performance is high
|
|||||
|
Melting Speed:
|
500 grams of copper. Silver. Gold. About 6 minutes.Graphite crucibles are necessary
|
|||||
|
Dimension
|
About (315long * 295 wide * 310 high) innovative design, small size, light weight.
|
|||||
Operation Steps — 2KG Silver Gold Iron Brass Mini Brass Melting Furnace — Economic Price with High Quality
2. Put the crucible in the coil, press the operation switch and turn the power to maximum.
3. Put the metal into the crucible.
4. Press the operation switch, turn power to maximum and start melting.
5. High-speed melting is proceeding.
6. About 5 mins, melting is finished, turn off the stop switch.
7. Use the plier to grab the crucible and pour the liquid metal into a graphite ingot mold.
8. Let the machine run in 1 min and then turn off the master switch & pull the plug
In the past five years,We value credit,abide by the contract,guarantee the product quality by the multi-variety management characteristic and the principle of small profits and large sales,has won the general customers' trust and the high praise.
Main Products–Jewelry Machines & Jewelry Tools
Our main products are jewelry machines & jewelry tools, including
2) Melting Furnace — used for melting & recycling the jewelry metals
3) Electric Furnace (oven) — used for de-waxing
4) Polishing Machine — used for polishing the jewel workpiece and make it perfect
5) Graphite Series — used for melting and making the shape of jewel workpiece
6) Ceramic Series — used for melting and making the shape of jewel workpiece
