150 meter ir distance 27x zoom outdoor ptz dome 5mp auto tracking ahd cctv camera
Camera:
HD 5.0Mpixes
1/3″ CMOS Sensor, 27x, f=4.7mm~94mm, D/N( ICR-Cut), DWDR , Color: 0.05lux, B/W:0.01lux.
Dome Features:
1. Auto tracking moving target according to movment ;
1. NEW 32 bit processor, with soft ID, more storage space, higher speed, better performance, lower consumption
2. Imported array IR LED, auto adjust zoom according to different distance
3. IR range 150M
4. With digital temperature controlling system protecting IR LED
5. 360 degree continued rotation, manual pan speed 0~240°/S, manual tilt speed 0~120°/S, preset speed 400°/S.
6.AHD output /TVI output / CVI output / CVBS output / D1 / AHD720P / AHD960H / AHD1080P / AHD 3.0MP / AHD 4.0MP / AHD 5.0MP output
7. 5 tours, DC12V
| Form parameters | ||
| Mode | Name and Description | ASHD698T-027-50 HD IR Auto Tracking High Speed Dome Camera |
| ASHD698T-027-50 Outdoor | ||
| Camera | Camera Name | AS-AH027 (27X D/N)) |
| Image Sensor | 1/3″ CMOS (NVP2477+05A10) | |
| Effective Pixels | 5.0 Mpixes | |
| Horizontal Resolution | 2592*1944 | |
| Min. Illumination | 0.05Lux :Color/0.01 Lux:B/W | |
| Zoom | 27X, f=4.7mm~94mm F1.6(W)~2.7(T) | |
| Day/Night | AUTO/COLOR/BW | |
| SNR | ≥50dB(AGC OFF) | |
| WDR | DWDR | |
| White Balance | Auto/Indoor/Outdoor/Manual | |
| Electronic shutter | 1/30s~1/10,000s | |
| Dome Features | CPU Type | 32 bit ARM CPU |
| Luminary | Array Φ20 6pcs | |
| Night vision distance | 150M | |
| Lamp control | Auto, Manual, by Zoom | |
| Address | 0~255(soft address and hard address) | |
| Pan Range | 360° continued rotation | |
| Tilt Range | 0~90°(Auto Flip) | |
| Manual pan speed | 0~240º/S | |
| Manual tilt speed | 0~120°/S | |
| Preset speed | 400°/S | |
| Actual preset Accuracy | ±0.10° | |
| Preset points | 255 | |
| Operation OSD language | Chinese /English | |
| OSD Display | dome menu & camera menu adjustment | |
| Home position | Return to preset/scan/pattern/ if there is no command in the specified period. |
|
| Operation recall | recall operation zone | |
| Tour | 5 | |
| Communication Protocol | Pelco D, Pelco P | |
| Intelligent Three dimensional Scan |
Auto Pan & Tilt &Zoom /Manual | |
| Pattern group | 3Programmable(Pan/Tilt/Zoom ) | |
| Speed adaption | Speed slows down automatically when zoom in | |
| Intelligent power off real time memory |
automatic save functions setting ,automatic wake up tour function | |
| Camera Menu operation | support the operation of camera set up | |
| Manual continued Auto Scan |
Non-limited position of manual continued Auto scan | |
| General | Work temperature | External–35℃~55℃ |
| Work Humidity | 0%~90% (Non condensing) | |
| Power | DC12V±10%; 5A | |
| Consumption | <50W | |
| Communication | RS-485 | |
| Video Output | AHD output /TVI output / CVI output / CVBS output / D1 / AHD720P / AHD960H / AHD1080P / AHD 3.0MP / AHD 4.0MP / AHD 5.0MP output | |
| Connection | BNC | |
Packading Details: Standard Paper Box Packing / Carton Packing
Delivery Detail: 3-7 working days after payment comfirmed
Anxinshi Technology Co.,Ltd is a manufacturer specializing in security surveillance products . Our company set the development, production, sales and service as a whole, Products include professional intelligence, digital and network video monitoring equipment. We take our clients with professional security video surveillance products and to meet customer demand system solutions as our responsibility,and also to provide customers with system design, product supply and assembly manufacturing, sales and trade cooperation integration services.
1. About the sample: How could I get a sample?
Once receive your payment for samples and their express delivery and then send samples to you. The prices of the samples are the same as those on the pricelist. Express delivery charge depends on the quantity of the samples.
2. About price list: can I get your price list?
Yes, please tell us the products (with their code number) and order quantity, then we will offer the price by e-mail. And our price list will keep updated every month.
3. About the shipment: what type of shipment will you use?
We usually ship the products by express delivery to your door or by air freight to your nearest airport. If the order quantity is large, we may ship by sea container.
4. About payment: what terms of payment do you use?
We accept TT (Telegraphic Transfer,MoneyGramor Western Union as payment term for small order and L/C for larger order.
5. About the MOQ: What is your minimum order qty?
Our minimum order qty is 20pcs each model, but we accept small order as trial order.
6,About compensation: what is your company’s compensation policy?
We can compensate buyer’s loss if our products have quality problem. For small qty problem products, we can replace with new products in next order. For larger qty problem products, we can accept returned problematic products, then we check them and replace them by good quality products.
7. About sole-distributor: How can I be your sole-distributor?
We have special policy for sole-distributor. Please contact our sales person to get related files.
8. About OEM: could we place order by OEM style to produce our own brand products in China?
Of course you can. Welcome to do OEM.
